Product Description
Ocmis R1 & 1A R-Series Irrigation Reel with Polyethylene Hose – Turbo Speed System | Durable Design
Included Options:
- Nozzle Sizes: Customizable nozzle sets (12mm to 22mm) depending on the model.
- Hose Lengths: Available in various lengths (250m, 280m, 300m).
- Raingun Options: Choose between the HYDRA and ROYAL raingun models based on your irrigation needs.
DESCRIPTION
The OCMIS R1 & 1A R-Series Irrigation Reels are part of Ocmis' highly regarded irrigation solutions, designed to offer superior performance and durability in agricultural applications. Known for their robustness and versatility, these models feature a turbo speed system that reduces turbine load loss, allowing for efficient operation even with low water flows and inlet pressures. With low running and maintenance costs, these reels are ideal for large-scale farming, delivering reliable irrigation across various types of terrain.
The R-Series is equipped with a polyethylene hose made from pure raw materials, ensuring long-lasting performance and durability. These reels are also designed with a mechanical lifting device, a three-speed gearbox, and trolley-mounted variable track wheels, making them adaptable and easy to operate for a variety of irrigation needs. Whether used for large crops or smaller agricultural applications, the R1 & 1A models are user-friendly and built to withstand the demands of continuous irrigation.
Key Features
- Low Running and Maintenance Costs: Designed for long-term, economical use.
- Versatility: Easily adaptable to various irrigation needs with user-friendly controls.
- Turbo Speed System: Reduces turbine load loss and allows efficient operation with low water flow.
- Polyethylene Hose: Constructed from pure raw materials for enhanced durability and performance.
- Mechanical Lifting Device: For ease of use when positioning the raingun trolley.
Technical Measurements (CM)
| Measurement | Value (CM) |
|---|---|
| A | 290 |
| B | 230 |
| C | 200 |
| D | 180 |
| E | 175 |
| F | 170 |
| G | 169 |
| H | 225 |
Detailed Specifications
| Specification | Details |
|---|---|
| Mechanical Lifting Device | Yes, for trolley positioning |
| Gearbox | 3-speed gearbox |
| Turbo Speed System | Reduces turbine load loss, allows variable machine speeds |
| Turbine | Flanged on the gearbox with built-in by-pass |
| Raingun Trolley | Galvanized, mounted on variable track wheels |
| Nozzle Types | HYDRA raingun (12mm to 16mm) and ROYAL raingun (16mm to 22mm) |
| Pressure Gauge | Glycerine bath pressure gauge |
| Speed Equalizer | Yes |
| Wheels | 2 wheels, mod. 205/60 R15 5F |
| Reel Coating | Epoxy resin coating with polyurethane paint |
| Hose Material | Polyethylene, made from unadulterated raw material |
| Telescopic Mechanical Feet | Yes |
| Power Take-Off (PTO) | Yes |
| Flexible Connection Pipe | Yes |
| Winding Handle | Yes |
| Safety Guards | Yes |
| Chassis and Turret | Hot galvanized for corrosion resistance |
| Double Water Inlet | Galvanized double water inlet |
| Available Hose Diameters (mm) | 63mm, 70mm, 75mm, 82mm |
| Available Hose Lengths (m) | 180m, 220m, 250m, 270m, 280m, 300m |
| Nozzle Sizes (HYDRA) | 12mm, 14mm, 16mm, 18mm |
| Nozzle Sizes (ROYAL) | 16mm, 18mm, 20mm, 22mm |
| Frame Material | Hot galvanized chassis and turret |
Available Hose Options
|
Hose Diameter (mm) |
Hose Length (m) |
Raingun |
Nozzles (mm) |
End Hose |
|---|---|---|---|---|
| 63 | 250 | HYDRA | 14/16/18 | G |
| 63 | 280 | HYDRA | 14/16/18 | I |
| 63 | 300 | HYDRA | 14/16/18 | J |
| 70 | 220 | ROYAL | 16/18/20 | F |
| 70 | 270 | ROYAL | 16/18/20 | J |
| 75 | 220 | ROYAL | 16/18/20 | G |
| 75 | 250 | ROYAL | 16/18/20 | I |
| 82 | 180 | ROYAL | 18/20/22 | A |
In Package
- OCMIS R1 or 1A R-Series Irrigation Reel
- Polyethylene hose (various lengths and diameters available)
- HYDRA or ROYAL raingun with a set of adjustable nozzles.
- Galvanized raingun trolley with variable track wheels.
- Mechanical lifting device for the raingun trolley.
- Three-speed gearbox with a turbo speed system.
- Pressure gauge and safety guards for secure operation.
- Operator’s manual for setup and maintenance.
