Product Description
OCMIS R2/1A & R2/1B R-Series Irrigation Reel With Polyethylene Hose | Turbo Speed System | Robust Design
Included Options:
- Nozzle Sizes: Customizable nozzles ranging from Ø 16mm to Ø 32mm.
- Hose Lengths: Available in different lengths, from 200m to 400m.
- Raingun Options: Choose between ROYAL and REFLEX rainguns depending on your irrigation requirements.
DESCRIPTION
The OCMIS R2/1A & R2/1B R-Series Irrigation Reels are engineered for heavy-duty agricultural irrigation, offering durability, efficiency, and ease of use. Designed with the needs of agriculturalists in mind, these models are built to deliver reliable irrigation over large areas, with low running and maintenance costs making them an economical choice for long-term use. The Turbo Speed System minimizes turbine load loss, allowing the reels to operate smoothly even at low flows and inlet pressures.
Equipped with high-quality ROYAL and REFLEX rainguns and a versatile set of nozzles (ranging from 16mm to 32mm), these reels can easily adapt to various irrigation needs. The robust polyethylene hose is made from unadulterated raw materials, ensuring durability and longevity.
The R2/1A & R2/1B models come with a mechanical lifting device, a 3-speed gearbox, and galvanized raingun trolleys, making them versatile, easy to operate, and highly efficient for irrigating larger fields.
Key Features
- Robust and High-Performing: Durable design ensures reliable performance over time.
- Economical Operation: Low running and maintenance costs for long-term savings.
- Turbo Speed System: Reduces turbine load loss, allowing for efficient operation with low flows.
- Versatility: Adaptable to various irrigation needs, thanks to its range of hose lengths and nozzle options.
- Polyethylene Hose: Made from unadulterated raw materials, ensuring long-lasting performance.
TECHNICAL FEATURES
| Measurement |
Value (CM) |
R2A Ø 90 - 250 MT |
Value (CM) |
|---|---|---|---|
| A | 325 | A | 325 |
| B | 265 | B | 270 |
| C | 235 | C | 240 |
| D | 225 | D | 230 |
| E | 195 | E | 195 |
| F | 193 | F | 193 |
| G | 199 | G | 199 |
| H | 255 | H | 255 |
Detailed Specifications
- Mechanical lifting device of trolley
- 3 Speed gearbox
- Turbine flanged on the gearbox with built-in by-pass
- Galvanized raingun trolley mounted on variable track wheels
- Set of nozzles ROYAL raingun from Ø 16 to Ø 22
- Pressure gauge (glycerine bath)
- Speed equalizer
- 2 wheels mod. 205/60 R15 5F
- Reel coated by epoxy resin and painted with polyurethane paint
- Galvanized double water inlet
- Telescopic mechanical feet
- Power take off
- Flexible connection pipe
- Raingun
- Set of nozzles REFLEX raingun from Ø 24 to Ø 32
- Winding handle
- Safety guards
- Hot galvanized chassis and turret
- Safety guards made of steel, swaged galvanized and painted
- Polyethylene hose made from unadulterated raw material
VERSIONS & PERFORMANCES - R2/1A
|
Hose Diameter (mm) |
Hose Length (m) |
Raingun |
Nozzles (mm) |
End Hose |
|---|---|---|---|---|
| 75 | 350 | ROYAL | 16/18/20 | D |
| 75 | 400 | ROYAL | 16/18/20 | D |
| 82 | 350 | ROYAL | 18/20/22 | E |
| 82 | 400 | ROYAL | 18/20/22 | C |
| 90 | 280 | REFLEX | 24/26/28 | H |
| 90 | 300 | REFLEX | 24/26/28 | I |
| 90 | 350 | REFLEX | 24/26/28 | B |
| 100 | 275 | REFLEX | 26/28/30 | I |
VERSIONS & PERFORMANCES - R2/1B
|
Hose Diameter (mm) |
Hose Length (m) |
Raingun |
Nozzles (mm) |
End Hose |
|---|---|---|---|---|
| 100 | 300 | REFLEX | 26/28/30 | I |
| 110 | 200 | REFLEX | 28/30/32 | C |
| 110 | 250 | REFLEX | 28/30/32 | I |
PERFORMANCE SUMMARY - 90X350
|
Flow Rate (GPM) |
Inlet Pressure (PSI) |
Sprinkler Pressure (PSI) |
Width 80% (FT) |
|---|---|---|---|
| 170 | 107 | 65 | 230 |
| 200 | 118 | 65 | 241 |
| 237 | 133 | 65 | 252 |
| 275 | 150 | 65 | 262 |
In Package
- OCMIS R2/1A or R2/1B R-Series Irrigation Reel
- Polyethylene Hose (various lengths and diameters available)
- ROYAL or REFLEX Raingun with adjustable nozzles
- Mechanical Lifting Device for easy positioning
- 3-Speed Gearbox for flexible operation
- Turbo Speed System for efficient performance under various pressures
- Safety Guards for secure operation
- Operator’s manual for setup and maintenance
