Ocmis R3A & R3/1A R-Series Irrigation Reel With Turbo Speed System | High Performance & Efficiency

Product Description

Ocmis R3A & R3/1A R-Series Irrigation Reel With Turbo Speed System | High Performance & Efficiency

Included Options:

• Hose Diameter: Choose from 82mm, 90mm, 100mm, 110mm, or 120mm based on irrigation needs.
• Hose Length: Available in lengths ranging from 230m to 500m for different field sizes.
• Raingun Models: Select between the ROYAL or REFLEX raingun models, depending on nozzle size and irrigation requirements.
• Nozzle Sizes: Customizable nozzles available in diameters from Ø 16mm to Ø 32mm

DESCRIPTION

The OCMIS R3A & R3/1A models from the R-Series Irrigation Reel Collection are renowned for their robustness, high performance, and versatility. Designed for large-scale agricultural irrigation, these reels are built to withstand demanding conditions while ensuring efficient and reliable performance over time. With a Turbo Speed System that reduces turbine load loss, these reels can operate at various machine speeds, even under low flow and inlet pressure conditions.

These models feature a 6-speed gearbox, a hydraulic lifting device for the trolley, and a galvanized raingun trolley, making them adaptable for different irrigation needs. With low running and maintenance costs, the R3A & R3/1A are an economical choice for farmers and agriculturalists, providing long-lasting service with reduced overall expenses.

Key Features

• Robust and High-Performing: Built for durability and designed to deliver reliable, efficient irrigation.
• Economical Operation: Low running and maintenance costs make these models an affordable long-term choice.
• Versatile and User-Friendly: Easy to use and adaptable to various irrigation needs, suitable for large-scale agricultural applications.
• Turbo Speed System: Reduces turbine load loss and allows operation with low water flows and inlet pressures.
• 6-Speed Gearbox: Provides flexibility in operation, allowing different machine speeds based on irrigation requirements.

Detailed Specifications

• Hydraulic lifting device of trolley
• 6 Speed gearbox
• Turbine flanged on the gearbox with built-in by-pass
• Galvanized raingun trolley mounted on variable track wheels
• Set of nozzles ROYAL raingun from Ø 16 to Ø 22
• Pressure gauge (glycerine bath)
• Speed equalizer
• Safety guards
• Hot galvanized chassis and turret
• Safety guards made of steel, swaged galvanized and painted
• For hose diam. 82-90-100 water inlet Bauer Ø 89
• Polyethylene hose made from unadulterated raw material
• Telescopic hydraulic feet
• Power take off
• Flexible connection pipe
• Raingun
• Set of nozzles REFLEX raingun from Ø 24 to Ø 32
• Winding handle
• Tachometer
• 2 wheels mod. 10.0/75-15.3 10PR 6F
• Reel coated by epoxy resin and painted with polyurethane paint
• Galvanized double water inlet
• For hose diam. 110 - 120 water inlet Bauer Ø 108

VERSIONS & PERFORMANCES

Technical Feature

In Package

• OCMIS R3A or R3/1A Irrigation Reel with Turbo Speed System
• ROYAL or REFLEX Raingun with adjustable nozzles (16mm to 32mm)
• Hydraulic lifting device for easy trolley positioning
• Polyethylene hose (82mm to 120mm diameter, various lengths available)
• Galvanized raingun trolley with variable track wheels
• 6-speed gearbox for flexible operation
• Pressure gauge for accurate inlet pressure monitoring
• Safety guards for secure and safe operation
• Power take-off for manual adjustments
• Operator’s manual for easy setup and maintenance
