Product Description
Ocmis TNO 125 L Slurry Sledge Lifting Tractor Pump – High-Performance Centrifugal Pump For Agricultural Applications
Included Options:
- Impeller RPM Options: Choose between 2500, 2700, or 2900 RPM depending on performance needs.
- Ratio Adjustments: Ratios available from 1:3.2 to 1:6.3 for customizable operation.
- Flow Capacity: Available in flow capacities ranging from 1000 L/min to 2500 L/min.
- Pump Head Heights: Adjustable pump heads ranging from 58m to 90m to accommodate varying lift and delivery requirements.
DESCRIPTION
The OCMIS TNO 125 L model is a high-performance centrifugal pump specifically designed for lifting sludge and other challenging materials in agricultural settings. Built to endure tough environments, this pump ensures efficient and reliable operation over long periods, making it an ideal choice for handling heavy-duty sludge and irrigation tasks. The TNO 125 L is engineered for immediate, optimized performance, providing farmers with a dependable solution for various irrigation needs.
Equipped with adjustable impeller RPM settings and multiple ratio options, the TNO 125 L can be tailored to fit specific requirements, offering versatility and power for a wide range of agricultural applications.
Key Features
- Durable Construction: Built for long-term use in demanding agricultural environments.
- High Performance: Optimized for immediate and efficient sludge lifting and irrigation.
- Versatile Ratios: Multiple ratio options (1:3.2 to 1:6.3) to customize performance.
- Powerful Impeller: Impeller RPM ranges from 2500 to 2900 for different flow capacities.
- Efficient Sludge Handling: Ideal for handling sludge and other challenging materials in agricultural applications.
Detailed Specifications
|
Impeller RPM |
Capacity (L/min) |
Pump Head (m) |
Absorbed Power (HP) |
|---|---|---|---|
| 2500 | 1000 | 65 | 38 |
| 2500 | 1500 | 62 | 45 |
| 2500 | 2000 | 60 | 50 |
| 2500 | 2500 | 58 | 57 |
| 2700 | 1000 | 77 | 45 |
| 2700 | 1500 | 75 | 53 |
| 2700 | 2000 | 72 | 60 |
| 2700 | 2500 | 70 | 67 |
| 2900 | 1000 | 90 | 58 |
| 2900 | 1500 | 88 | 68 |
| 2900 | 2000 | 85 | 78 |
| 2900 | 2500 | 83 | 85 |
Technical Feature
| Value | |
|---|---|
| A | / |
| B | 150 |
| C | 114 |
| D | / |
| E | 310 |
| F | 355 |
| G | 264 |
| H |
In Package
- OCMIS TNO 125 L Centrifugal Pump
- Flexible connection pipe for easy installation with existing systems.
- Pre-installed impeller for immediate operation.
- Safety guards to ensure secure and safe operation.
- Set of nozzles for adjustable flow and capacity.
- Operator’s Manual: Provides setup, usage, and maintenance instructions.
