Product Description
Ocmis VIR9 Vario Rain Series Irrigation Reel With Galvanized Double Water Inlet
Included Options:
- REFLEX, LANCER, or EXPLORER rainguns.
- Nozzle sizes from Ø 24 mm to Ø 42 mm.
- Hose diameters from 110 mm to 160 mm.
- Hose lengths up to 850 meters.
- End hose configurations: A, B, C, E, H, I, J
DESCRIPTION
The OCMIS VIR9 Vario Rain Series irrigation reel is dsigned for efficient and reliable irrigation, offering versatility and high performance across various agricultural applications. Built with a synchronized 4-speed VR gearbox, the VIR9 ensures smooth operation and optimal water usage. Its adaptability allows agriculturalists to easily adjust the system to meet their irrigation needs while minimizing water consumption. With features that enhance ease of use and consistent performance, the VIR9 guarantees effective irrigation with minimal pressure losses.
The durable construction of the VIR9 includes a hot-galvanized chassis and epoxy-coated reel, ensuring long-lasting protection against corrosion and wear. It is equipped with various raingun options, including REFLEX, LANCER, and EXPLORER, allowing for customized irrigation based on field conditions. The hydraulic system, complete with telescopic hydraulic feet and power take-off, makes setup and operation convenient for users, while the Aqua System computer ensures precise control over water distribution.
Key Features
- 4-speed synchronized VR gearbox for efficient irrigation.
- Water-saving design reduces water consumption while maintaining performance.
- Minimal pressure losses for consistent and reliable irrigation.
- Hot-galvanized chassis and reel for enhanced durability and corrosion resistance.
- User-friendly design for ease of operation.
- Telescopic hydraulic feet for stable setup.
- Polyethylene hose made from high-quality raw materials for durability.
- Raingun options: REFLEX, LANCER, and EXPLORER with variable nozzle sizes.
- Safety guards made from galvanized steel for added protection.
- Aqua System computer for precise irrigation control.
Technical Features
| Category | Measurement (CM) |
|---|---|
| A | 490 |
| B | 427 |
| C | 402 |
| D | 378 |
| E | 265 |
| F | 312 |
| G | 345 |
| H | 250 |
Detailed Specifications
| Feature | VIR9 Specification |
|---|---|
| Wheel Chassis | Included |
| Hydraulic Turntable Rotation | Included |
| Hydraulic Drawbar Lifting | Included |
| Gearbox | 4 Speed VR |
| Flexible Connection Pipe | Included |
| Pressure Gauge | Glycerine bath |
| Nozzles (REFLEX Raingun) | Ø 24 to Ø 32 |
| Nozzles (LANCER Raingun) | Ø 30 to Ø 40 |
| Aqua System Computer | Included |
| Hydraulic System (Tractor Couplings) | Included |
| Wheels | 150/70-18 148A8 14PR 6F |
| Safety Guards | Galvanized steel, swaged, painted |
| Water Inlet | Bauer Ø 133 |
| Hydraulic Lifting Device (Trolley) | Included |
| Telescopic Hydraulic Feet | Included |
| Power Take Off | Included |
| Turbine | Flanged with double built-in by-pass |
| Raingun Trolley | Galvanized, mounted on variable track wheels |
| Raingun | Included |
| Nozzles (EXPLORER Raingun) | Ø 28 to Ø 40 |
| Winding Handle | Included |
| Hose Retraction | Double chain |
| Chassis and Reel Coating | Hot galvanized, epoxy resin, polyurethane paint |
| Water Inlet | Galvanized double |
| Hose Material | Polyethylene, unadulterated raw material |
Versions & Performances
|
Hose Diameter / Hose Length |
Raingun / Nozzles (mm) |
End Hose |
|---|---|---|
| 110 mm / 800 m | REFLEX / 26/28/30 | E |
| 110 mm / 850 m | REFLEX / 26/28/30 | C |
| 125 mm / 680 m | EXPLORER / 28/30/32 | J |
| 135 mm / 600 m | EXPLORER / 34/36/38 | I |
| 140 mm / 530 m | EXPLORER / 34/36/38 | B |
| 150 mm / 450 m | EXPLORER / 36/38/40 | C |
| 150 mm / 480 m | EXPLORER / 36/38/40 | A |
| 160 mm / 350 m | EXPLORER / 38/40/42 | H |
| 160 mm / 380 m | EXPLORER / 38/40/42 | J |
In Package
- VIR9 Vario Rain Series irrigation reel.
- Aqua System computer for precise control.
- REFLEX, LANCER, or EXPLORER raingun with a full set of nozzles.
- Hydraulic system for lifting and rotating the turntable.
- Flexible connection pipe for easy setup.
- Double chain hose retraction system.
- Telescopic hydraulic feet for stability.
- Glycerine bath pressure gauge for accurate pressure reading.
- Hot-galvanized chassis and reel with epoxy resin and polyurethane paint.
