Quick Solenoid Box Kit - 150A - 12V [FVSGRCT15012A00]

Quick Solenoid Box Kit - 150A - 12V [FVSGRCT15012A00]

Regular price $498.82
Regular price $0.00 Sale price $498.82
Sale Sold out
Customizable
Fast
24/7 Support

Solenoid Box Kit - 150A - 12V

Single-direction solenoid box kit, designed primarily for Quick BTQ series bow and stern thrusters.

Specifications:

  • Voltage & Amperage: 12V DC / 150 Amps
  • Contactor Type: Single pole, single throw (non-reversing)
  • Ingress Protection: IP66 waterproof casing (excluding exposed terminals)
  • Motor Capacity: Handles thruster motors up to 3.3 kW

Direct replacement for the following Quick BTQ thruster models: BTQ 125-30 / BTQ 125-40, BTQ 185-55 / BTQ 185-65 / BTQ 185-75 / BTQ 185-85

While optimized for bow thrusters, these heavy-duty solenoids are also suited to single-direction electrical marine components including:

  • Anchor windlasses
  • Electric capstans
  • High-current winch motors
View full details
