RINIERI

Rinieri Double Sickle Bar Pruning Machine | CRL Tower 2-I Series | Cutting Width 59"-83" inches | Horsepower 50-70 HP | For Tractors

Rinieri Double Sickle Bar Pruning Machine | CRL Tower 2-I Series | Cutting Width 59"-83" inches | Horsepower 50-70 HP | For Tractors

$1.00
$1.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Pricing Unavailable, Request Quote
  • Hydraulic Lifting Mechanism: Provides a 27.5" vertical lift for optimal pruning height.
  • Tilt Functionality: Hydraulic vertical tilt of +/- 20° and manual adjustment of +/- 11°.
  • Double Blade Cutting Bars: Ensures clean, precise cuts with robust dual-blade movement.
  • Hydraulic Side Shift: Allows flexible positioning for efficient operation.
  • Safety Mechanisms: Spring-loaded controls and pressure protection for enhanced user safety.
  • Modular Design: Customizable and upgradable to meet future pruning needs.
View full details

How To Get A Quote

***Online pricing not available, Please request a quote:***

How To Get A Quote:

Option 1:
“Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!

Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!

Product Description

Rinieri Double Sickle Bar Pruning Machine | CRL Tower 2-I Series | Cutting Width 59"-83" inches | Horsepower 50-70 HP | For Tractors

DESCRIPTION

DOUBLE SICKLE BAR PRUNING MACHINE CRL TOWER-2 I is a powerful, adaptable machine designed for precision pruning in agricultural and landscaping applications. Built with a strong central frame and equipped with hydraulic lifting and tilting functions, the CRL TOWER-2 I offers flexibility and ease of use. Its double blade cutting bars ensure accurate and clean cuts, while its spring safety controls and manual closures ensure safe transportation and operation. The machine’s modular design allows for modifications after purchase, giving users more control and adaptability based on their pruning needs.

Key Features

  • Hydraulic Lifting: Achieves a vertical lift of 27.5" (70 cm) for easy adjustment.
  • Vertical Frame Tilt: Vertical frame tilts +/- 20° hydraulically for precise cutting angles.
  • Side Shifting: Hydraulic side shift for flexible pruning operations.
  • Manual Vertical Bar Tilt: Allows a manual tilt adjustment of +/- 11° for versatility.
  • Double Blade Cutting Bars: Robust design ensures clean, accurate cuts using double-blade tooth movement.
  • Safety Features: Includes spring-loaded safety controls for vertical bars and a maximum pressure valve for motor protection.
  • Modular Design: Can be modified after purchase, offering flexibility for future needs.

Detailed Specifications


Model A (cm) C (cm) D (cm) Oil Demand (L/min) Required Horsepower (HP)
CRL T2 A 150 150 75 - 135 125 - 185 20 - 30 50-70
CRL T2 B 150 150 105 - 185 155 - 235 20 - 30 50-70
CRL T2 C 150 150 160 - 260 215 - 315 20 - 30 50-70
CRL T2 A 180 180 75 - 135 125 - 185 20 - 30 50-70
CRL T2 B 180 180 105 - 185 155 - 235 20 - 30 50-70
CRL T2 C 180 180 160 - 260 215 - 315 20 - 30 50-70
CRL T2 B 210 210 105 - 185 155 - 235 20 - 30 50-70
CRL T2 C 210 210 160 - 260 215 - 315 20 - 30 50-70

Manuals & Documents

The Product Manual

General Warranty Info:

  • Ripping It Outdoors works closely with our manufacturers to supply and support your products warranty needs as best as possible!
  • The majority of products come with a manufacturer represented warranty against manufacturing defects for at least a 12 month period after the date of sale.
  • Expendable components and "wear parts" including but not limited to blades, knives, teeth, oil, chain sprockets, skid shoes, knife mounting discs, and similar components are usually excluded from manufacturer warranties.
  • Please reach out to us for any specific warranty information needed about products and parts you can’t find!

Videos

Shipping

$1 Shipping Quote Info:

  • Contact Us For Shipping Quotes. All $1 products are listed as quote only because we can not display their pricing online.
  • Low shipping rates for customers. We have negotiated the best possible rates for customers from our trusted carriers (ODFL, ESTES, UPS, and FedEx) & Top Private Drivers
  • Negotiate shipping rates if you think we can do better please reach out. Keep in mind some shipping rates also include assembly & configuration as well!
  • Complimentary lift gate service on all freight shipments where it’s possible. We guarantee safe delivery!
