Product Description
Shearex Mulcher | Model VM-60SR | Cutting Width 59" inches | Machine Size 20-25 Tons | For Excavators
Ripping It is Partnered with Quality Equipment to provide the best pricing and service for SHEAREX
DESCRIPTION
The Shearex VM-60SR is a robust forestry mulcher attachment designed for excavators in the 20–25 tons class. With a precise cutting width of 58.75 inches, this high-performance mulcher excels in forestry mulching, land clearing, roadside maintenance, and underbrush management. Its advanced features deliver optimal durability, efficiency, and control on challenging terrains.
Key Features
- Customizable Cutting Options: Choose between carbide teeth or blades to match your specific operational needs.
- CONVEX DX™ Protection System: Provides superior durability and efficiency with advanced material management technology.
- G 2.0 Balance Quality: Ensures smooth, stable, and high-performance operation.
- Optimized Blade Angle: Precision-designed for a perfect cut, maintaining cutting efficiency throughout the blade’s lifespan.
- Compatibility: Designed for 20-25 ton excavators (44,000 to 55,000 lbs) with a minimum carrier power of 130 HP.
- Superior Cutting Performance: 58.75-inch cutting width and 21 blades on the rotor, optimized for materials up to 15 inches in diameter.
- CONVEX DX™ Protection System: Features advanced fins to limit material cut per pass, enhancing durability and efficiency.
- Hydraulic Efficiency: 42 gal/min flow rate and 6,000 psi operating pressure with a 3,000 rpm rotor speed.
- Customizable Options: Choose between carbide teeth or blades and add optional grapple and tilt systems for enhanced functionality.
| Image | Feature | Description |
 |
Coupling | Shearex provides the standard attachment bracket to couple the mulcher to the carrier. Shearex is also able to make a coupleradapted to any brand of carrier you might have. |
 |
Tilting System | Essential tool for facilitating work at height for the operator of an excavator by more easily visualizing the trajectory of the mulcher’s rotor. |
 |
Optional Grapple System |
Move and sort through smaller material or pile them up for greater mulching control. |
Detailed Specification
| Specification | Details |
|---|---|
| Excavator Size | 20 to 25 tons (44,000 to 55,000 lbs) |
| Recommended Minimum Power | 130 HP (96 kW) |
| Cutting Width | 58.75 inches (149 cm) |
| Material Diameter | Up to 15 inches (40 cm) |
| Rotor Diameter | 17.7 inches (45 cm) |
| Number of Blades | 21 |
| Weight | 2,614 lbs (1,188 kg) |
| Hydraulics Flow Rate | 42 gal/min (159 l/min) |
| Operating Pressure | 6,000 psi (410 bar) |
| Cutting Distance | 0.25 inches (0.64 cm) from ground |
| Exterior Dimensions | Length: 77 in, Width: 28 in, Height: 35 in |
| Rotor Speed | 3,000 rpm |
| Pulley Ratio | 1:2:1 |
