Product Description
Sicma (Phoenix) 3-Point Rotary Tiller | T5 Series | Working Width 52", 56" & 60" inches | Horsepower 20-35 HP | For Tractors
DESCRIPTION
Elevate your farming, landscaping, or grounds maintenance operations with the Phoenix T5 Series Rotary Tillers. Crafted by the renowned Italian manufacturer Sicma, these tillers are engineered for excellence, combining durability, efficiency, and versatility. Whether you're a hobby farmer, vineyard owner, landscaper, or gardener, the Phoenix T5 Series is the perfect partner for soil conditioning, weed control, fertilizer incorporation, and seedbed preparation.
Available in working widths from 52 to 60 inches, these rotary tillers feature robust construction and come fully equipped with essential components like a heavy-duty slip clutch PTO and 6 tines per flange to ensure smooth operation and exceptional results.
Key Features
- Six Tines Per Flange: Ensures efficient and thorough tillage, creating finely tilled soil for planting.
- Adjustable/Offsettable Hitch Blocks: Allows up to 4 inches of offset for precision tilling along rows or edges.
- Oil Level Site Glass: Features a drive housing oil level site glass for easy maintenance, ensuring optimal performance and longevity.
- Zinc-Plated Heavy Duty Jack Stand: Multi-position jack stand, resistant to rust and wear, for dependable support during maintenance and storage.
- Heavy Duty Adjustable Drag Board: Equipped with a zinc-plated check chain, this feature provides maximum control over soil depth and smooth operation.
- Powder Coat Paint Finish: Coated in an attractive and durable orange finish, offering corrosion resistance and a polished look.
- Standard PTO Shaft with Slip Clutch: Comes with a Eurocardan Series 4 PTO shaft featuring slip clutch protection for safe and efficient operation.
- Pre-Filled Gear Oil: Shipped with gear oil already in the center gearbox and rotor drive, saving you time and effort.
- Easy Assembly: Minimal assembly required, so you can get started quickly and easily.
Detailed Specifications
| Feature | UNI-PHO-T5-52 | UNI-PHO-T5-56 | UNI-PHO-T5-60 |
|---|---|---|---|
| SKU | UNI-PHO-T5-52 | UNI-PHO-T5-56 | UNI-PHO-T5-60 |
| Weight | 396 lbs | 430 lbs | 441 lbs |
| Identifier | PHO-1488 | PHO-1493 | PHO-1969 |
| Model | T5-52 | T5-56 | T5-60 |
| Horsepower Recommended | 20 - 35 HP (14.9 - 26.1 KW) | 20 - 35 HP (14.9 - 26.1 KW) | 20 - 35 HP (14.9 - 26.1 KW) |
| Width - Overall | 52" (132 cm) | 56" (142 cm) | 66" (5-1/2 Feet; 168 cm) |
| Width - Working | 52" (132 cm) | 56" (142 cm) | 60" (5 Feet; 152 cm) |
| Tines / Rods | 36 Total - 6 Blades per Flange; 6 Flanges | 42 Total - 6 Blades per Flange; 7 Flanges | 42 Total - 6 Blades per Flange; 7 Flanges |
| Tilling Depth | Up to 7" (18 cm) | Up to 7" (18 cm) | Up to 7" (18 cm) |
| Unit Drive Type | 540 RPM Rear Tractor PTO | 540 RPM Rear Tractor PTO | 540 RPM Rear Tractor PTO |
| PTO Shaft | Included, with Heavy Duty Slip Clutch Protection | Included, with Heavy Duty Slip Clutch Protection | Included, with Heavy Duty Slip Clutch Protection |
| Rotor Shaft Drive Type | #80 Chain Driven | #80 Chain Driven | #80 Chain Driven |
| Skid Shoes | Adjustable and Replaceable, Included | Adjustable and Replaceable, Included | Adjustable and Replaceable, Included |
| Parking Stand | Included Standard | Included Standard | Included Standard |
| Hitch Connection Type | Category 1, 3-Point Hitch | Category 1, 3-Point Hitch | Category 1, 3-Point Hitch |
| Color | Orange | Orange | Orange |
Manual & Documents
General Warranty Info:
-
Ripping It Outdoors works closely with our manufacturers to supply and support your products warranty needs as best as possible!
- The majority of products come with a manufacturer represented warranty against manufacturing defects for at least a 12 month period after the date of sale.
- Expendable components and "wear parts" including but not limited to blades, knives, teeth, oil, chain sprockets, skid shoes, knife mounting discs, and similar components are usually excluded from manufacturer warranties.
- Please reach out to us for any specific warranty information needed about products and parts you can’t find!
