STOUT | HD Walk-Through Pallet Fork Frame | Grade 50 Steel | Forks 48"-72" | Up to 5,500 lb Capacity| Class 2 | Forged Fork Rail | 8-Position Adjustment | For Skid Steers
STOUT | HD Walk-Through Pallet Fork Frame | Grade 50 Steel | Forks 48"-72" | Up to 5,500 lb Capacity| Class 2 | Forged Fork Rail | 8-Position Adjustment | For Skid Steers
Regular price
$529.00
Regular price
Sale price
$529.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
STOUT | HD Walk-Through Pallet Fork Frame | Grade 50 Steel | Forks 48"-72" | Up to 5,500 lb Capacity| Class 2 | Forged Fork Rail | 8-Position Adjustment | For Skid Steers
DESCRIPTION
Engineered for strength, precision, and operator comfort, the STOUT HD Skid Steer Walk-Through Pallet Fork Frame and Forks delivers unmatched durability and performance for your heaviest lifting tasks. Constructed entirely from high-strength Grade 50 steel, this premium attachment is built to handle the most demanding job sites while maintaining smooth functionality and ease of use.
The walk-through spill guard and forged fork rail are designed for operator safety and efficiency, while the side step provides convenient access to your skid steer. Whether you're lifting pallets, moving construction materials, or tackling agricultural loads, this heavy-duty system provides a secure and adjustable fit with 6-position pin-style fork spacing and fork options ranging from 48" to 72", with load capacities up to 5,500 lbs. at a 24" load center.
Key Features
- Heavy-Duty Grade 50 Steel Frame – Designed for strength, resilience, and longevity.
- Forged Fork Rail – Enhances frame durability and fork stability under load.
- Walk-Through Spill Guard – Allows easy access and improved operator visibility.
- Integrated Side Step – Convenient and safe entry/exit for the operator.
- 6-Position Pin-Style Fork Adjustment – Quick and secure spacing customization.
- High Load Ratings – Up to 5,500 lbs. at 24" load center.
- Multiple Fork Length Options – Choose between 48", 60", or 72" forks.
- Universal Skid Steer Mount – Fits most major skid steer brands.
Detailed Specifications
| Feature | Details |
|---|---|
| Mount Type | Universal Skid Steer |
| Construction Material | High-Strength Grade 50 Steel |
| Fork Class | Class 2 |
| Fork Length Options | 48", 60", 72" |
| 48" Fork Capacity (Option 1) | 4,000 lbs. at 24" load center |
| 48" Fork Capacity (Option 2) | 5,500 lbs. at 24" load center |
| 60" Fork Capacity | 5,500 lbs. at 24" load center |
| 72" Fork Capacity | 5,500 lbs. at 24" load center |
| Frame Width | 46" |
| Frame Height | 36" |
| Frame Depth (Only) | 6.5" |
| Approx. Weight (w/ 48" Forks) | 450 lbs. |
| Fork Spacing Adjustment | 6-Position Pin-Style |
| Spill Guard | Walk-Through Style – Included |
| Side Step | Included – Built-In |
| Ideal Use | Construction, Agriculture, Material Handling |
| Manufacturing Origin | USA |
Comparision Chart
| Feature | Pro WT/FB | HD2 WT/FB |
|---|---|---|
| Model Name | Stout Pro Walk-Through Full Back Frame | Stout HD2 Walk-Through Full Back Frame |
| Material | Heavy-Duty Steel | High Strength Grade 50 Steel (50,000 PSI) |
| Fork Frame Weight (48") | Approx. 415 lbs | Approx. 450 lbs |
| Frame Width | 46" | 46" |
| Frame Height | 31.5" | 36" |
| Frame Depth | Not specified | 6.5" (Frame Only) |
| Fork Options | 48", 60", 72" | 48", 60", 72" |
| Fork Ratings @ 24" Load Center | 4000 lbs (48") 5500 lbs (48", 60", 72") |
4000 lbs (48") 5500 lbs (48", 60", 72") |
| Fork Class | Class 2 | Class 2 |
| Fork Spacing Adjustment | 8-Position Pin Style | 6-Position Pin Style |
| Spill Guard Type | Walk-Through Full Guard – Removable | Walk-Through Full Guard – Welded (with Side Step) |
| Side Step | Yes – Removable | Yes – Integrated Side Step |
| Forged Fork Rail | No | Yes |
| Compatibility | Universal Skid Steer Quick Attach | Universal Skid Steer Quick Attach |
| Country of Origin | Made in the USA | Made in the USA |
