Stout XHD Utility Grapple | Width 76" & 84" inches | Oil Flow Range 14-23 GPM | For Skid Steers

Stout XHD Utility Grapple | Width 76" & 84" inches | Oil Flow Range 14-23 GPM | For Skid Steers

Regular price $3,078.90
Regular price Sale price $3,078.90
Sale Sold out
Machine Compatibility
Customizable
Fast
24/7 Support
  • Oil Flow Range 14-23 GPM For Skid Steers
  • Heavy-Duty Steel Build: Made entirely of Grade 50 Steel, designed to handle high stress and extreme conditions.
  • Two Width Options: Available in 76" and 84" widths for diverse operational needs
  • Replaceable Parts for Durability: Equipped with 7-inch tine spacing, ½-inch tine thickness, and replaceable spreader bar caps for prolonged usability.
View full details

Product Description

Stout XHD Utility Grapple | Width 76" & 84" inches | Oil Flow Range 14-23 GPM | For Skid Steers

DESCRIPTION

The Stout Skid Steer XHD Utility Grapple is a Heavy-Duty Grapple engineered to endure demanding conditions with ease. Constructed with Grade 50 Steel (50,000 psi strength), this utility grapple is designed for skid steers and is ideal for handling tough tasks like land clearing, debris management, and large material handling. Available in 76" and 84" widths, it features tines, stiffener bars, and durable hydraulic cylinders that ensure efficient and consistent operation. Compatible with skid steers using oil flow rates of 14-23 GPM, this grapple provides exceptional versatility and performance.

Key Features

  • Heavy-Duty Steel Build: Made entirely of Grade 50 Steel, designed to handle high stress and extreme conditions.
  • Two Width Options: Available in 76" and 84" widths for diverse operational needs.
  • Replaceable Parts for Durability: Equipped with 7-inch tine spacing, ½-inch tine thickness, and replaceable spreader bar caps for prolonged usability.
  • Hydraulic Adjustments: Automatically balances uneven bucket loads during operation for optimal performance.
  • Fully Greaseable Components: Ensures smooth operation and extended lifespan with greaseable pivots at critical points.
  • Enhanced Hose Protection: All hydraulic hoses are sleeved for protection and secured with a hose keeper block to prevent damage in pinch points.
  • Wide Grapple Opening: Offers a 39-inch grapple opening for secure handling of oversized materials.
  • Hydraulic Cylinder Specifications: 2-inch bore and 8-inch stroke for strong and precise performance under load.
  • Universal Skid Steer Mount: Features a Quick Attach Mount for compatibility with most skid steers.
  • Oil Flow Compatibility: Operates efficiently in the 14-23 GPM flow range for smooth hydraulic performance.

Detailed Specifications

Attribute Details
Width Options 76", 84"
Weight (Unit/Shipping) 76": 900 lbs / 940 lbs; 84": 945 lbs / 985 lbs
Depth 42 inches
Height 30 inches
Tine Spacing 7 inches
Tine Thickness ½ inch
Spreader Bar Thickness ½ inch
Number of Stiffener Bars 2 (full bucket width)
Grapple Width 21 inches
Grapple Opening 39 inches
Hydraulic Cylinders 2-inch bore, 8-inch stroke
Couplers ½" Flat Face
Material Grade 50 Steel (50,000 psi)
Oil Flow Range 14-23 GPM
Protection Features Hydraulic cylinder covers, sleeved hoses, and hose keeper block
Made In USA
