Product Description
TAG Quick Coupler Ditch Cleaning Bucket | 1¼" T-Pin | 30"–42" Width | Machine Size 6–7 Ton | For Excavators
DESCRIPTION
The TAG Quick Coupler Ditch Cleaning Bucket Series is engineered to optimize precision grading, trench dressing, and ditch shaping for excavators in the 12,000–14,000 lb (6–7 ton) class. Featuring a Quick Coupler mounting system with 1.25" T-pin connection, these buckets offer rapid interchange capability and high structural integrity during finish work.
Each bucket incorporates a double-radius, dual taper profile to enhance material flow and reduce carry-back. The shell design includes double bottom construction, while internal rib reinforcements (on wider models) add exceptional strength. A double-beveled, reversible bolt-on cutting edge ensures extended wear life and maintenance convenience, making these buckets ideal for clean-up, final passes, and precise earth shaping.
Key Features
- Machine Class Compatibility: Excavators from 12,000–14,000 lbs (6–7 ton class).
- Mount System: Quick Coupler with 1.25" vertical T-pin interface.
- Bucket Profile: Dual taper and double-radius geometry for smooth trench shaping.
- Shell Design: Double-bottom structure enhances durability and service longevity.
- Reinforcements: Internal ribs added on wider models to resist torsion and side impact.
- Cutting Edge: Reversible bolt-on edge with double bevel for efficient penetration and wear resistance.
- Opening Geometry: Smooth, unobstructed openings for clear material discharge.
- Application Use: Ditch cleaning, slope grading, trench finishing, and contour work.
-
Availability: Common sizes stocked; call LEC or TAG MFG for confirmation and lead times.
Detailed Specifications
Model: 3028QD
| Attribute | Specification |
|---|---|
| Order # | 3028QD |
| Width | 30″ |
| Capacity | 0.227 yd³ |
| Weight | 295 lbs |
Model: 3628QD
| Attribute | Specification |
|---|---|
| Order # | 3628QD |
| Width | 36″ |
| Capacity | 0.276 yd³ |
| Weight | 310 lbs |
Model: 4228QD
| Attribute | Specification |
|---|---|
| Order # | 4228QD |
| Width | 42″ |
| Capacity | 0.325 yd³ |
| Weight | 330 lbs |
Host Machine Compatibility
| BRAND | MODELS |
| BOBCAT | |
| CASE | |
| CAT | |
| DEERE | 60G |
| DOOSAN |
|
| GEHL | |
| HITACHI | ZX60 |
| HYUNDIA | |
| IHI | |
| JCB | 8055, 8065, 57C |
| KOBELCO | |
| KOMATSU | PC27Mr-2, PC35Mr-2 |
| KUBOTA | U55 |
| MUSTANG | |
| NEW HOLLAND | |
| TAKEUCHI | TB145, TB153, TB250, TB260 |
| TEREX | |
| VOLVO | ECR58 |
| WACKER | |
| YANMAR |
