Tanco Round Bale Wrapper | D66-S300-V | Width 54" | 30-60 GPM | 40-60 HP | For Skid Steers, Tractors & Loaders
Tanco Round Bale Wrapper | D66-S300-V | Width 54" | 30-60 GPM | 40-60 HP | For Skid Steers, Tractors & Loaders
Regular price
$50,580.00
Regular price
Sale price
$50,580.00
Unit price
per
Couldn't load pickup availability
Machine Compatibility
Couldn't load pickup availability
Product Description
Tanco Round Bale Wrapper | D66-S300-V | Width 54" | 30-60 GPM | 40-60 HP | For Skid Steers, Tractors & Loaders
DESCRIPTION
The Tanco D66-S300-V S Series Round Bale Wrapper is an advanced, high-performance tool designed to enhance your farming productivity. With the capability to wrap and stack bales in one seamless operation, this machine is perfect for farmers looking to save time and reduce labor costs. Weighing just 1,587 lbs, it’s built for all-terrain use, including mountainous conditions. The versatile wrapper allows you to choose between single, twin, or triple wrap arms, making it ideal for varying bale sizes and output requirements. Thanks to its automatic wrapping cycle, patented telescopic Cut & Start, and variable speed hydraulics, this Tanco Round Bale Wrapper ensures a smooth, reliable operation every time. Designed to maximize bale protection and reduce handling, the S Series is your ultimate solution for efficient hay and straw management.
Key Features
- Compact & Lightweight: Weighing only 1,587 lbs, ideal for rugged terrain and high bale count.
- Wrap & Stack in One Operation: Save time and reduce labor by wrapping and stacking bales together.
- Automatic & Efficient: The automatic wrapping cycle ensures fast, consistent results with minimal effort.
- Flexible Wrap Arms: Choose between single, twin, or triple wrap arms for varying bale outputs.
- Telescopic Cut & Start System: A patented feature that extends and retracts for reliable film gathering and cutting.
- Variable Speed Hydraulics: Adjustable wrap arm speed for smoother operation and reduced machine wear.
- End-Tip Option Available: Ensure plastic coverage at its best while preventing bales from rolling.
- Film Break Sensors: For precise and efficient film management, minimizing film wastage.
- Dual Stretch Dispenser: Available with 55% and 70% stretch options for enhanced wrapping quality.
- Individually Driven Rollers: Offers efficient, smooth bale handling and wrapping without disruptions.
- Ground Roller Option: Helps stabilize the machine when used with lighter tractors.
- Optional Remote Control: Control wrapping operations from a distance for added convenience.
- Proportional Hydraulic Functionality: Ensures a smoother, more consistent wrapping process.
- Minimized Bale Movement: Wrap arms rotate under the bale, reducing movement during wrapping.
- RDS Expert Plus Controller: For precise machine control and easy operation.
- Durable Construction: Built to last, even in the toughest farming environments.
Detailed Specifications
| Feature | D66-S300-V S Series |
|---|---|
| Weight | 1,587 lbs (720 kg) |
| Transport Length | 7' 5" (2.30 m) |
| Transport Width | 4' 6" (1.40 m) |
| Height in Transport | 7' 8" (2.40 m) |
| Bale Width | 4' (1.25 m) |
| Min. Bale Diameter | 40" (1.00 m) |
| Max. Bale Diameter | 60" (1.50 m) |
| Max. Bale Weight | 2,645 lbs (1,200 kg) |
| Hydraulic Flow (Min) | 8 GPM (30 L/min) |
| Hydraulic Flow (Max) | 16 GPM (60 L/min) |
| Horsepower | 40-60 HP |
| Hydraulic Flow | 30-60 GPM |
| Hydraulic Pressure | 2,600 PSI (180 bar) |
| Free Flow Return Required | Yes |
| Load Sensing | Yes |
| Remote Control Option | Yes |
| Automatic Cut & Start | Yes |
| Pre-Stretcher Options | One (30”) available |
