The Taylor TD1000 Standby Diesel Generator is a reliable and powerful solution for emergency power needs. Rated at 1000kW, it is UL2200 ETL-certified, ensuring high-quality standards. With a robust Mitsubishi V-12 Turbocharged engine, this generator is designed to deliver exceptional performance and endurance. It comes equipped with a range of optional features to cater to individual customer requirements, making it a versatile choice for industrial and commercial applications.
Taylor Power System Standby-Diesel Generators | Model TD-1000 | Horsepower 1474 HP | Power Output 1000kW (1250kVA) | Open & Enclosed Unit
Taylor Power System Standby-Diesel Generators | Model TD-1000 | Horsepower 1474 HP | Power Output 1000kW (1250kVA) | Open & Enclosed Unit
Regular price
$1.00
Regular price
Sale price
$1.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
How To Request A Quote
***Online pricing not available, Please request a quote:***
How To Get A Quote:
Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!
Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!
Product Description
Taylor Power System Standby-Diesel Generators | Model TD-1000 | Horsepower 1474 HP | Power Output 1000kW (1250kVA) | Open & Enclosed Unit
DESCRIPTION
Key Features
- Engine: Mitsubishi S12H-Y2PTAW-1, 37.11L Turbocharged V-12, EPA Tier 2 Certified
- Output Power Options: Multiple voltage configurations with up to 1250kVA
- Construction: Heavy-duty steel base with vibration isolators
- Fuel Efficiency: Supports low-sulfur diesel with advanced fuel injection
- Durability: Factory powder coating, test-certified for rugged use
- Cooling System: High ambient unit-mounted radiator
- Electric System: DC 24 volts with 4 required batteries
- Emission Compliance: EPA Certified for stationary emergency use
- Ease of Maintenance: Oil drain valve with extension, battery rack, and cables
- Sound Level: Operates at 113 dBA at 3.2 ft
- Safety Features: Over-voltage, under-frequency, and over-excitation protection
| Control Panels | Feature | Description |
 |
DeepSea 7310 MKII | Simultaneous Use of RS232 & RS485, Modbus RTU Support, Fully Configurable Using USB, RS232 &RS485, IP65 Rating 6 Programmable Inputs & 8 Outputs UL & cUL Listed and CE Certified |
 |
Basler DGC2020 | SAE J1939 Engine ECU, Communications, 4 Programmable Inputs & 10 Outputs Modbus Communications With RS485 UL Recognized, CSA & CE Certified IP 54 Front Panel Rating NFPA 110 Level 1 Compatible Manual Override Keyswitch DGC2020HD Variant Available |
 |
Taylor Analog | Automatic CANBUS Engine Control Gauge Zeroing on Shutdown Auto-Off-Manual Control Switch Oil Pressure, Water Temperature, Battery Voltage and RPM Gauges AC Voltage, Frequency, Percent of Load, and Run-Time Metering LED Status Lights |
Detailed Specifications
| Category | Details |
|---|---|
| Engine Make | Mitsubishi S12H-Y2PTAW-1 |
| Engine Type | 37.11L Turbocharged V-12, Tier 2 |
| Fuel Type | Diesel |
| Output Ratings | 1000kW/1250kVA |
| Cooling Capacity | 26.4 gal (100.0 L) |
| Compression Ratio | 14.5:1 |
| Horsepower | 1474 @ 1800 RPM |
| Fuel Consumption | 75.0 gal/hr (284 L/hr) at 100% load |
| Alternator Type | Marathon PMG with hybrid analog/digital voltage regulator |
| Voltage Regulation | ±0.25% |
| Temperature Rise | 125°C Standby |
| Heat Rejection | To coolant: 417 kW (23,715 BTUM) |
Enhanced Alternator Features
-
Stamford Alternator:
- NEMA H insulation for superior durability.
- Complies with global standards such as BS EN 60034 and IEC 34-1.
- Designed to withstand overspeeds of up to 125%.
-
Marathon Alternator:
- Features NEMA N insulation and hybrid analog/digital regulation.
- Provides robust performance with <0.25% voltage variance.
Customizable Control Panels
-
DeepSea 7310 MKII:
- Fully configurable using USB, RS232, and RS485 connections.
- IP65-rated for resistance against dust and water ingress.
-
Basler DGC2020:
- NFPA 110 Level 1 compliant, offering advanced diagnostics and fault monitoring.
- Modbus-compatible with programmable outputs for enhanced control.
Customization Options
-
Open Unit Accessories:
- Radiator duct flange, critical silencers, and flexible exhaust configurations.
-
Enclosed Unit Features:
- Sound attenuation, sub-base fuel tanks, and load centers with GFI receptacles.
-
Additional Accessories:
- Includes vibration isolators, battery heaters, oil pan heaters, and block heaters for optimal performance in challenging environments.
 |
Open Unit | Overall Size: 174”L x 80”W x 100”H Approximate Weight: 22,100 lbs. |
 |
Standard Enclosed Unit | N/A |
