The Taylor Power TD250 is a top-tier, EPA-certified stationary emergency generator designed for heavy-duty industrial and commercial applications. Equipped with the powerful Perkins 1706D-E93TAG1 engine and cutting-edge alternators, it provides unmatched reliability and efficiency in critical power situations.
Taylor Power System Standby-Diesel Generators | Model TD-250 | Horsepower 377 HP | Power Output 250kW (313kVA) | Open & Enclosed Unit
Taylor Power System Standby-Diesel Generators | Model TD-250 | Horsepower 377 HP | Power Output 250kW (313kVA) | Open & Enclosed Unit
Regular price
$1.00
Regular price
Sale price
$1.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
How To Request A Quote
***Online pricing not available, Please request a quote:***
How To Get A Quote:
Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!
Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!
Product Description
Taylor Power System Standby-Diesel Generators | Model TD-250 | Horsepower 377 HP | Power Output 250kW (313kVA) | Open & Enclosed Unit
DESCRIPTION
Key Features
-
High Power and Performance:
- Rated at 250/313 kW/kVA, capable of powering large-scale operations.
- Supports various voltage configurations, including 277/480V, 120/208V, and 120/240V, in both single-phase and three-phase setups.
-
Outstanding Engine:
- Features the Perkins 1706D-E93TAG1 turbocharged engine with an impressive 376.54 horsepower at 1800 RPM.
- Advanced air-to-air charge cooling for enhanced performance and durability.
- Isochronous governor ensures precise speed regulation of ±0.25%.
-
Efficient Alternator Options:
- Stamford PMG: Outstanding voltage regulation with up to 1.0% (single-phase) and 0.5% (three-phase) accuracy, with high cooling airflow of 2,100 CFM.
- Marathon PMG: Hybrid analog/digital voltage regulation with <0.25% variance and cooling airflow of 1,020 CFM.
-
Superior Fuel Efficiency:
- Electronic fuel injection system achieves optimized consumption at 16.55 gal/hr (100% load) and significantly lower consumption at part loads.
- Operates on low-sulfur diesel fuel, meeting EPA Tier 3 standards.
-
Advanced Control Panels:
- Choose between DeepSea 7310 MKII or Basler DGC2020, both with Modbus RTU compatibility, multiple programmable inputs/outputs, and user-friendly monitoring capabilities.
-
Noise Reduction:
- Open unit operates at 115 dBA (at 1 meter).
- Optional sound-attenuated enclosure reduces noise to 80.3 dBA (at 7 meters), ideal for urban and noise-sensitive environments.
-
Customizable Options:
- Available in open or enclosed units with additional accessories to meet unique operational needs.
| Control Panels | Feature | Description |
 |
DeepSea 7310 MKII | Simultaneous Use of RS232 & RS485, Modbus RTU Support, Fully Configurable Using USB, RS232 &RS485, IP65 Rating 6 Programmable Inputs & 8 Outputs UL & cUL Listed and CE Certified |
 |
Basler DGC2020 | SAE J1939 Engine ECU, Communications, 4 Programmable Inputs & 10 Outputs Modbus Communications With RS485 UL Recognized, CSA & CE Certified IP 54 Front Panel Rating NFPA 110 Level 1 Compatible Manual Override Keyswitch DGC2020HD Variant Available |
 |
Taylor Analog | Automatic CANBUS Engine Control Gauge Zeroing on Shutdown Auto-Off-Manual Control Switch Oil Pressure, Water Temperature, Battery Voltage and RPM Gauges AC Voltage, Frequency, Percent of Load, and Run-Time Metering LED Status Lights |
Detailed Specifications
| Feature | Details |
|---|---|
| Engine | Perkins 1706D-E93TAG1 (9.3L, Turbocharged) |
| Horsepower | 376.54 HP at 1800 RPM |
| Power Output | 250/313 kW/kVA |
| Voltage Options | 277/480V, 120/208V, 120/240V |
| Alternator Options | Stamford or Marathon PMG |
| Voltage Regulation | Stamford: 1.0% (single-phase), 0.5% (three-phase); Marathon: <0.25% |
| Fuel Consumption | 16.55 gal/hr (100% load), 8.70 gal/hr (50% load) |
| Sound Level | 80.3 dBA (enclosed unit at 7 meters) |
| Dimensions (Open Unit) | 120"L x 57"W x 74"H |
| Weight (Open Unit) | 5,500 lbs |
| Dimensions (Enclosed Unit) | 162"L x 66"W x 81"H |
| Weight (Enclosed Unit) | 7,750 lbs |
 |
Open Unit | Overall Size: 120”L x 57”W x 74”H Approximate Weight: 5,500 lbs. |
 |
Standard Enclosed Unit | Overall Size: 162”L x 66”W x 81”H Approximate Weight: 7,750 lbs. |
