The Taylor TD500 is a robust, EPA-certified standby diesel generator designed to deliver reliable and efficient power for demanding applications. Equipped with the powerful Perkins 2506D-E15TAG3 engine, it meets the needs of industrial and commercial operations, ensuring uninterrupted performance during critical power outages.
Taylor Power System Standby-Diesel Generators | Model TD-500 | Horsepower 728 HP | Power Output 500kW (625kVA) | Open & Enclosed Unit
Taylor Power System Standby-Diesel Generators | Model TD-500 | Horsepower 728 HP | Power Output 500kW (625kVA) | Open & Enclosed Unit
Regular price
$1.00
Regular price
Sale price
$1.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
How To Request A Quote
***Online pricing not available, Please request a quote:***
How To Get A Quote:
Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!
Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!
Product Description
Taylor Power System Standby-Diesel Generators | Model TD-500 | Horsepower 728 HP | Power Output 500kW (625kVA) | Open & Enclosed Unit
DESCRIPTION
Key Features
-
Exceptional Power Output:
- Rated at 500/625 kW/kVA, offering high capacity for intensive operations.
- Multiple voltage configurations, including 277/480V, 120/208V, and 120/240V, to suit diverse applications.
-
High-Performance Perkins Engine:
- Powered by the Perkins 2506D-E15TAG3 turbocharged engine, delivering an impressive 727.62 horsepower at 1800 RPM.
- Advanced air-to-air charge cooling ensures optimal efficiency and durability.
- Isochronous governor enables precise speed regulation with ±0.25% accuracy.
-
Efficient Alternators:
- Stamford PMG: Exceptional voltage regulation with 1.0% accuracy for single-phase and 0.5% for three-phase, requiring high cooling airflow of 2,780 CFM.
- Marathon PMG: Features hybrid analog/digital voltage regulation with <0.25% variance, requiring 1,520 CFM cooling airflow.
-
Fuel Efficiency:
- Optimized fuel system with consumption of 34.87 gal/hr at 100% load, adhering to EPA Tier 2 standards.
- Operates on low-sulfur diesel fuel for eco-friendly performance.
-
Advanced Control Panels:
- Options include DeepSea 7310 MKII and Basler DGC2020, offering programmable inputs/outputs and real-time monitoring via Modbus RTU.
- Easy-to-use interface for efficient operation and diagnostics.
-
Noise Reduction Options:
- Open unit produces 105.2 dBA at 1 meter.
- Sound-attenuated enclosure reduces noise to 80.3 dBA at 7 meters, ideal for noise-sensitive environments.
| Control Panels | Feature | Description |
 |
DeepSea 7310 MKII | Simultaneous Use of RS232 & RS485, Modbus RTU Support, Fully Configurable Using USB, RS232 &RS485, IP65 Rating 6 Programmable Inputs & 8 Outputs UL & cUL Listed and CE Certified |
 |
Basler DGC2020 | SAE J1939 Engine ECU, Communications, 4 Programmable Inputs & 10 Outputs Modbus Communications With RS485 UL Recognized, CSA & CE Certified IP 54 Front Panel Rating NFPA 110 Level 1 Compatible Manual Override Keyswitch DGC2020HD Variant Available |
 |
Taylor Analog | Automatic CANBUS Engine Control Gauge Zeroing on Shutdown Auto-Off-Manual Control Switch Oil Pressure, Water Temperature, Battery Voltage and RPM Gauges AC Voltage, Frequency, Percent of Load, and Run-Time Metering LED Status Lights |
Detailed Specifications
| Feature | Details |
|---|---|
| Engine | Perkins 2506D-E15TAG3 (15.2L, Turbocharged) |
| Horsepower | 727.62 HP at 1800 RPM |
| Power Output | 500/625 kW/kVA |
| Voltage Options | 277/480V, 120/208V, 120/240V |
| Alternator Options | Stamford or Marathon PMG |
| Voltage Regulation | Stamford: 1.0% (single-phase), 0.5% (three-phase); Marathon: <0.25% |
| Fuel Consumption | 34.87 gal/hr (100% load) |
| Sound Level | 80.3 dBA (enclosed unit at 7 meters) |
| Dimensions (Open Unit) | 142"L x 53"W x 84"H |
| Weight (Open Unit) | 8,000 lbs |
| Dimensions (Enclosed Unit) | 192"L x 66"W x 102"H |
| Weight (Enclosed Unit) | 10,650 lbs |
Enhanced Alternator Features
-
Stamford Alternator:
- NEMA H insulation for superior durability.
- Complies with global standards such as BS EN 60034 and IEC 34-1.
- Designed to withstand overspeeds of up to 125%.
-
Marathon Alternator:
- Features NEMA N insulation and hybrid analog/digital regulation.
- Provides robust performance with <0.25% voltage variance.
Customizable Control Panels
-
DeepSea 7310 MKII:
- Fully configurable using USB, RS232, and RS485 connections.
- IP65-rated for resistance against dust and water ingress.
-
Basler DGC2020:
- NFPA 110 Level 1 compliant, offering advanced diagnostics and fault monitoring.
- Modbus-compatible with programmable outputs for enhanced control.
Customization Options
-
Open Unit Accessories:
- Radiator duct flange, critical silencers, and flexible exhaust configurations.
-
Enclosed Unit Features:
- Sound attenuation, sub-base fuel tanks, and load centers with GFI receptacles.
-
Additional Accessories:
- Includes vibration isolators, battery heaters, oil pan heaters, and block heaters for optimal performance in challenging environments.
 |
Open Unit | Overall Size: 142”L x 53”W x 84”H Approximate Weight: 8,000 lbs. |
 |
Standard Enclosed Unit | Overall Size: 192”L x 66”W x 102”H Approximate Weight: 10,650 lbs. |
