The TD600 is a robust EPA-certified stationary emergency generator set, powered by the Perkins 2806C-E18TAG3 engine. Designed for standby power needs, it offers exceptional durability and performance. Equipped with Stamford or Marathon alternators, it ensures efficient power delivery with advanced voltage regulation and safety features.
Taylor Power System Standby-Diesel Generators | Model TD-600 | Horsepower 874 HP | Power Output 600kW (750kVA) | Open & Enclosed Unit
Taylor Power System Standby-Diesel Generators | Model TD-600 | Horsepower 874 HP | Power Output 600kW (750kVA) | Open & Enclosed Unit
Regular price
$1.00
Regular price
Sale price
$1.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
How To Request A Quote
***Online pricing not available, Please request a quote:***
How To Get A Quote:
Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!
Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!
Product Description
Taylor Power System Standby-Diesel Generators | Model TD-600 | Horsepower 874 HP | Power Output 600kW (750kVA) | Open & Enclosed Unit
DESCRIPTION
Key Features
- Engine: Perkins 2806C-E18TAG3, EPA Tier 2, turbocharged with air-to-air charge cooling.
- Alternators: Stamford and Marathon options featuring precise voltage regulation, overvoltage, and under-frequency protection.
- Control Panels: Includes DeepSea 7310 MKII, Taylor Analog, or Basler DGC2020 for comprehensive control and monitoring.
- Fuel System: MEUI fuel injection with low sulfur diesel compatibility.
- Sound Control: Optional sound-attenuated enclosure for reduced noise levels (108 dBA at 1 meter for open units).
- Construction: Heavy-duty steel base, vibration isolators, and powder-coated finish for longevity.
- Cooling System: Optimized airflow and coolant capacity for effective thermal management.
- Versatility: Available in single and three-phase configurations with varied output options.
| Control Panels | Feature | Description |
 |
DeepSea 7310 MKII | Simultaneous Use of RS232 & RS485, Modbus RTU Support, Fully Configurable Using USB, RS232 &RS485, IP65 Rating 6 Programmable Inputs & 8 Outputs UL & cUL Listed and CE Certified |
 |
Basler DGC2020 | SAE J1939 Engine ECU, Communications, 4 Programmable Inputs & 10 Outputs Modbus Communications With RS485 UL Recognized, CSA & CE Certified IP 54 Front Panel Rating NFPA 110 Level 1 Compatible Manual Override Keyswitch DGC2020HD Variant Available |
 |
Taylor Analog | Automatic CANBUS Engine Control Gauge Zeroing on Shutdown Auto-Off-Manual Control Switch Oil Pressure, Water Temperature, Battery Voltage and RPM Gauges AC Voltage, Frequency, Percent of Load, and Run-Time Metering LED Status Lights |
Detailed Specifications
| Category | Details |
|---|---|
| Output Power Options | Standby Rating up to 750 kVA |
| Voltage Options | 600V, 277/480V, 120/208V, 120/240V |
| Phase | Single-phase / Three-phase |
| Engine | Perkins 2806C-E18TAG3 |
| Net Horsepower | 873.68 HP |
| Rated RPM | 1800 |
| Fuel Type | Low Sulfur Diesel |
| Sound Levels | 108 dBA (open unit, 1m distance) |
| Dimensions | Open Unit: 146”L x 66”W x 84”H <br> Enclosed Unit: 220”L x 76”W x 96”H |
| Weight | Open Unit: ~8,600 lbs <br> Enclosed Unit: ~12,500 lbs |
| Cooling Capacity | 16.11 gal (61.00 L) |
Enhanced Alternator Features
-
Stamford Alternator:
- NEMA H insulation for superior durability.
- Complies with global standards such as BS EN 60034 and IEC 34-1.
- Designed to withstand overspeeds of up to 125%.
-
Marathon Alternator:
- Features NEMA N insulation and hybrid analog/digital regulation.
- Provides robust performance with <0.25% voltage variance.
Customizable Control Panels
-
DeepSea 7310 MKII:
- Fully configurable using USB, RS232, and RS485 connections.
- IP65-rated for resistance against dust and water ingress.
-
Basler DGC2020:
- NFPA 110 Level 1 compliant, offering advanced diagnostics and fault monitoring.
- Modbus-compatible with programmable outputs for enhanced control.
Customization Options
-
Open Unit Accessories:
- Radiator duct flange, critical silencers, and flexible exhaust configurations.
-
Enclosed Unit Features:
- Sound attenuation, sub-base fuel tanks, and load centers with GFI receptacles.
-
Additional Accessories:
- Includes vibration isolators, battery heaters, oil pan heaters, and block heaters for optimal performance in challenging environments.
 |
Open Unit | Overall Size: 146”L x 66”W x 84”H Approximate Weight: 8,600 lbs. |
 |
Standard Enclosed Unit | Overall Size: 220”L x 76”W x 96”H Approximate Weight: 12,500 lbs. |
