The Taylor TG100 is a robust and versatile 100kW standby generator designed to operate on both Natural Gas (NG) and Liquid Propane (LP). Engineered with a turbocharged, air-cooled GM 5.7L V-8 engine, it ensures optimal performance during power outages. ETL Certified to UL2200 standards, the TG100 combines high efficiency, advanced controls, and durable construction to meet a wide range of residential, commercial, and industrial backup power needs.
Taylor Power System Standby-NG/LP Generator | Model TG-100 | Horsepower 149-160 HP | Power Output 100kW (125kVA) | Open & Enclosed Unit
Taylor Power System Standby-NG/LP Generator | Model TG-100 | Horsepower 149-160 HP | Power Output 100kW (125kVA) | Open & Enclosed Unit
Regular price
$1.00
Regular price
Sale price
$1.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
How To Request A Quote
***Online pricing not available, Please request a quote:***
How To Get A Quote:
Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!
Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!
Product Description
Taylor Power System Standby-NG/LP Generator | Model TG-100 | Horsepower 149-160 HP | Power Output 100kW (125kVA) | Open & Enclosed Unit
DESCRIPTION
Key Features
Engine Performance:
- GM 5.7L Turbocharged and Air-Cooled V-8 Engine.
- Delivers 160.9 HP on Natural Gas and 149.1 HP on LP Vapor.
- Isochronous governor for precise ±0.50% speed regulation.
- Rated at 100kW with a standby power output of 125 kVA.
Dual Fuel Compatibility:
- Operates on both Natural Gas and Liquid Propane (LP) for added flexibility.
- Fuel supply pressure: 7-11 in. H₂O (1.74-2.74 kPa).
Efficient Operation:
- Fuel consumption for Natural Gas:
- 100% Load: 1389 CFH (39.9 m³/hr)
- 75% Load: 1134 CFH (32.1 m³/hr)
- Fuel consumption for LP Vapor:
- 100% Load: 538 CFH (15.2 m³/hr)
- 75% Load: 436 CFH (12.3 m³/hr).
Durability:
- Heavy-duty steel base with vibration isolators for improved stability and durability.
- Factory powder coating provides corrosion resistance.
- High ambient unit-mounted radiator ensures efficient cooling.
Advanced Controls:
- Options include:
- DeepSea 7310 MKII: IP65 rated with Modbus RTU support.
- Basler DGC2020: NFPA 110 Level 1 compatibility and RS485 communications.
- Taylor Analog: User-friendly with vital engine and electrical gauges.
Superior Alternators:
-
Marathon PMG Alternator:
- Voltage Regulation: 0.25%.
- NEMA Class N insulation.
-
Stamford PMG Alternator:
- Voltage Regulation: 0.50%.
- NEMA Class H insulation.
Certifications & Safety:
- ETL Certified to UL2200, EPA compliant, and CE & CSA certified.
- Safety features include over-voltage, under-frequency, and over-excitation protections.
| Control Panels | Feature | Description |
 |
DeepSea 7310 MKII | Simultaneous Use of RS232 & RS485, Modbus RTU Support, Fully Configurable Using USB, RS232 &RS485, IP65 Rating 6 Programmable Inputs & 8 Outputs UL & cUL Listed and CE Certified |
 |
Basler DGC2020 | SAE J1939 Engine ECU, Communications, 4 Programmable Inputs & 10 Outputs Modbus Communications With RS485 UL Recognized, CSA & CE Certified IP 54 Front Panel Rating NFPA 110 Level 1 Compatible Manual Override Keyswitch DGC2020HD Variant Available |
 |
Taylor Analog | Automatic CANBUS Engine Control Gauge Zeroing on Shutdown Auto-Off-Manual Control Switch Oil Pressure, Water Temperature, Battery Voltage and RPM Gauges AC Voltage, Frequency, Percent of Load, and Run-Time Metering LED Status Lights |
Detailed Specifications
General
| Category | Specification |
|---|---|
| Engine | GM 5.7L Turbocharged, Air-Cooled V-8 |
| Fuel Type | Natural Gas (NG) / Liquid Propane (LP) |
| Horsepower | 160.9 HP (NG) / 149.1 HP (LP) |
| Power Output | 100kW / 125kVA |
| Rated RPM | 1800 |
| Compression Ratio | 9.1:1 |
| Displacement | 5.7 L (350.0 in³) |
| Cooling Capacity | 2.1 gal (7.8 L) |
| Oil Capacity | 5.0 qt (4.7 L) |
| Exhaust Temp | 1200°F (649°C) |
| Air Flow | Combustion: 262.0 CFM (7.4 m³/min) / Radiator: 5,500 CFM (156 m³/min) |
| Fuel Consumption (Natural Gas) | 1389 CFH (39.9 m³/hr) at 100% Load |
| Fuel Consumption (LP Vapor) | 538 CFH (15.2 m³/hr) at 100% Load |
| Exhaust Outlet Size | 4.0 in (101.6 mm) |
| Control Panels | DeepSea 7310 MKII, Taylor Analog, Basler DGC2020 |
| Voltage Regulation | Marathon PMG: 0.25% / Stamford PMG: 0.50% |
| Certifications | UL2200, EPA, CE, CSA |
Engine Data
| Category | Specification |
|---|---|
| Manufacturer | PSI |
| Model | 5.7L |
| Aspiration | TCAC |
| Arrangement | V-8, 4-Cycle |
| Firing Order | 1-8-4-3-6-5-7-2 |
| Displacement | 5.7 L (350.0 in³) |
| Bore | 101.60 mm (4.00 in) |
| Stroke | 88.4 mm (3.48 in) |
| Compression Ratio | 9.1:1 |
| Gross Horsepower (Natural Gas) | 160.9 HP |
| Gross Horsepower (LP Vapor) | 149.1 HP |
| Rated RPM | 1800 |
| Governor | Isochronous |
| Speed Regulation | ±0.50% |
| Category | Specification |
|---|---|
| Engine Liquid Capacity |
Oil System: 5.0 qt (4.7 L) Cooling Capacity: 2.1 gal (7.8 L) |
| Engine Electrical |
Electric Volts: DC 12 Cold Cranking Amps: 650 Battery(s) Required: 1 |
| Fuel System |
Fuel Supply Size: Natural Gas: 1.25” NPT LP Vapor: 1.25” NPT Supply Pressure: 7-11 in. H₂O (1.74-2.74 kPa) |
| Air Requirements |
Air Filter(s) Type: Dry Combustion Air Flow: 262.0 CFM (7.4 m³/min) Maximum Air Intake Restriction: Clean: 3.00 in. H₂O (1.49 kPa) Dirty: 13.00 in. H₂O (3.24 kPa) Radiator Air Flow: 5,500 CFM (156 m³/min) |
| Exhaust System |
Gas Temperature: 1200°F (649°C) Gas Flow: 845.9 CFM (24.0 m³/min) Max Back Pressure: 40.9 in. H₂O (10.2 kPa) Exhaust Outlet Size: 4.0 in (101.6 mm) |
| Filters and Quantity |
Air Cleaner Quantity: 1 Oil Filter(s) Quantity: 1 |
| Fuel Consumption (Natural Gas) |
100% Power: 1389 CFH (39.9 m³/hr) 75% Power: 1134 CFH (32.1 m³/hr 50% Power: 879 CFH (24.9 m³/hr)<br>25% Power: 624 CFH (17.7 m³/hr) |
| Fuel Consumption (LP Vapor) |
100% Power: 538 CFH (15.2 m³/hr) 75% Power: 436 CFH (12.3 m³/hr) 50% Power: 334 CFH (9.5 m³/hr) 25% Power: 232 CFH (6.6 m³/hr) |
 |
Open Unit | Overall Size: 78”L x 36”W x 50”H Approximate Weight: 2,000 lbs. |
 |
Standard Enclosed Unit | Overall Size: 120”L x 52”W x 64”H Approximate Weight: 3,700 lbs. |
