The Taylor TG25 Standby Generator is a reliable and compact solution for powering essential systems during outages. With its 25kW rating and support for both Natural Gas (NG) and Liquid Propane (LP), it is versatile for various applications. Powered by a robust PSI 2.4L Inline 4-cylinder engine, the TG25 is ETL Certified to UL2200, ensuring compliance and quality. Its compact size and multiple output configurations make it an ideal choice for small businesses and residential installations.
Taylor Power System Standby-NG/LP Generator | Model TG-25 | Horsepower 42-46 HP | Power Output 25kW (31kVA) | Open & Enclosed Unit
Taylor Power System Standby-NG/LP Generator | Model TG-25 | Horsepower 42-46 HP | Power Output 25kW (31kVA) | Open & Enclosed Unit
Regular price
$1.00
Regular price
Sale price
$1.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
How To Request A Quote
***Online pricing not available, Please request a quote:***
How To Get A Quote:
Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!
Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!
Product Description
Taylor Power System Standby-NG/LP Generator | Model TG-25 | Horsepower 42-46 HP | Power Output 25kW (31kVA) | Open & Enclosed Unit
DESCRIPTION
Key Features
- Engine: PSI 2.4L Inline 4-cylinder, naturally aspirated, EPA Certified
- Horsepower: 42.81 HP (Natural Gas) / 46.52 HP (LP Vapor) at 1800 RPM
- Output Power Options: Supports various voltage configurations up to 31kVA
- Compact Design: Built with a heavy-duty steel base and vibration isolators
- Fuel Versatility: Compatible with Natural Gas and Liquid Propane
- Cooling System: High ambient unit-mounted radiator for efficient cooling
- Ease of Maintenance: Oil drain valve with extension, battery rack, and cables
- Emission Compliance: EPA Certified for stationary emergency use
- Safety Features: Overload, under-frequency, and voltage adjustment protection
- Sound Management: Operates with a balanced exhaust system
| Control Panels | Feature | Description |
 |
DeepSea 7310 MKII | Simultaneous Use of RS232 & RS485, Modbus RTU Support, Fully Configurable Using USB, RS232 &RS485, IP65 Rating 6 Programmable Inputs & 8 Outputs UL & cUL Listed and CE Certified |
 |
Basler DGC2020 | SAE J1939 Engine ECU, Communications, 4 Programmable Inputs & 10 Outputs Modbus Communications With RS485 UL Recognized, CSA & CE Certified IP 54 Front Panel Rating NFPA 110 Level 1 Compatible Manual Override Keyswitch DGC2020HD Variant Available |
 |
Taylor Analog | Automatic CANBUS Engine Control Gauge Zeroing on Shutdown Auto-Off-Manual Control Switch Oil Pressure, Water Temperature, Battery Voltage and RPM Gauges AC Voltage, Frequency, Percent of Load, and Run-Time Metering LED Status Lights |
Detailed Specifications
| Category | Details |
|---|---|
| Engine Make | PSI 2.4L |
| Engine Type | 2.4L Inline 4-cylinder, naturally aspirated |
| Fuel Type | Natural Gas / Liquid Propane |
| Horsepower | 42.81 HP (NG) / 46.52 HP (LP Vapor) at 1800 RPM |
| Output Ratings | 25kW/31kVA |
| Compression Ratio | 9.5:1 |
| Fuel Supply Size | 0.75” NPT |
| Cooling Capacity | 4,752 CFM Radiator Air Flow |
| Fuel Consumption | NG: 0.359 lb/hp-hr / LP Vapor: 0.377 lb/hp-hr (100% load) |
| Voltage Regulation | ±1.0% |
| Temperature Rise | 125°C Standby |
| Sound Level | dBA levels depend on configuration and distance |
 |
Open Unit | Overall Size: 60”L x 38”W x 44”H Approximate Weight: xxxx lbs. |
 |
Standard Enclosed Unit | Overall Size: 78”L x 46”W x 46”H Approximate Weight: 1,500 lbs |
