The Taylor Power TG40 is a robust 40kW standby generator powered by Natural Gas (NG) or Liquid Propane (LP). It is ETL Certified to UL2200 standards, making it a reliable and efficient choice for residential, commercial, or industrial power backup needs. Designed with flexibility in mind, it offers various customization options to meet specific requirements, ensuring maximum performance and durability.
Taylor Power System Standby-NG/LP Generator | Model TG-40 | Horsepower 66-71 HP | Power Output 40kW (50kVA) | Open & Enclosed Unit
Taylor Power System Standby-NG/LP Generator | Model TG-40 | Horsepower 66-71 HP | Power Output 40kW (50kVA) | Open & Enclosed Unit
Regular price
$1.00
Regular price
Sale price
$1.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
How To Request A Quote
***Online pricing not available, Please request a quote:***
How To Get A Quote:
Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!
Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!
Product Description
Taylor Power System Standby-NG/LP Generator | Model TG-40 | Horsepower 66-71 HP | Power Output 40kW (50kVA) | Open & Enclosed Unit
DESCRIPTION
Key Features
-
Engine & Fuel:
- GM 4.3L Natural Aspirated V-6 Engine.
- Supports NG/LP fuel types.
- Isochronous governor with ±0.50% speed regulation.
- EPA Certified as a Stationary Emergency Unit.
-
Durability & Design:
- Heavy-duty steel base with vibration isolators.
- Factory powder coating for added protection.
- High ambient unit-mounted radiator.
-
User Convenience:
- Oil drain valve with extension for easy maintenance.
- Battery rack and cables included.
- Comprehensive owner’s manual provided.
-
Control Panel Options:
- DeepSea 7310 MKII with Modbus RTU support.
- Taylor Analog with auto-off-manual control switch.
- Basler DGC2020 featuring programmable inputs/outputs and NFPA 110 compatibility.
-
Alternator:
- Marathon alternator with PMG type, NEMA Class N insulation.
- Hybrid analog/digital voltage regulation (0.25%).
-
Certifications & Protections:
- CE, CSA Certified, and UL Listed.
- Over-voltage and under-frequency protection.
- Designed to handle overspeeds up to 125%.
| Control Panels | Feature | Description |
 |
DeepSea 7310 MKII | Simultaneous Use of RS232 & RS485, Modbus RTU Support, Fully Configurable Using USB, RS232 &RS485, IP65 Rating 6 Programmable Inputs & 8 Outputs UL & cUL Listed and CE Certified |
 |
Basler DGC2020 | SAE J1939 Engine ECU, Communications, 4 Programmable Inputs & 10 Outputs Modbus Communications With RS485 UL Recognized, CSA & CE Certified IP 54 Front Panel Rating NFPA 110 Level 1 Compatible Manual Override Keyswitch DGC2020HD Variant Available |
 |
Taylor Analog | Automatic CANBUS Engine Control Gauge Zeroing on Shutdown Auto-Off-Manual Control Switch Oil Pressure, Water Temperature, Battery Voltage and RPM Gauges AC Voltage, Frequency, Percent of Load, and Run-Time Metering LED Status Lights |
Detailed Specifications
| Category | Specification |
|---|---|
| Engine | GM 4.3L, V-6, Natural Aspiration |
| Fuel Type | Natural Gas (NG) / Liquid Propane (LP) |
| Rated RPM | 1800 |
| Power Output | 40kW |
| Alternator | Marathon PMG, 0.25% Voltage Regulation |
| Cooling Capacity | 1.92 gal (7.30 L) |
| Oil System Capacity | 4.50 qt (4.25 L) |
| Exhaust Temp | 1200°F (649°C) |
| Fuel Consumption | NG: 584 CFH @ 100% |
| Certifications | EPA Certified, UL2200, CE, CSA |
 |
Open Unit | Overall Size: 78”L x 36”W x 50”H Approximate Weight: xxxx lbs |
 |
Standard Enclosed Unit | Overall Size: 102”L x 52”W x 64”H Approximate Weight: 2,200 lbs. |
