The Taylor TG80 is an advanced 80kW standby generator built for reliable performance during power outages. Designed to operate on Natural Gas (NG), it features a turbocharged GM 5.7L V-8 engine and is ETL Certified to UL2200 standards, ensuring safety and reliability. This generator combines durability, efficiency, and intelligent control options to cater to various residential, commercial, and industrial power backup needs. Its robust construction and user-friendly features make it an exceptional choice for demanding applications.
Taylor Power System Standby-NG/LP Generator | Model TG-80 | Horsepower 124 HP | Power Output 80kW (100kVA) | Open & Enclosed Unit
Taylor Power System Standby-NG/LP Generator | Model TG-80 | Horsepower 124 HP | Power Output 80kW (100kVA) | Open & Enclosed Unit
Regular price
$1.00
Regular price
Sale price
$1.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
How To Request A Quote
***Online pricing not available, Please request a quote:***
How To Get A Quote:
Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!
Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!
Product Description
Taylor Power System Standby-NG/LP Generator | Model TG-80 | Horsepower 124 HP | Power Output 80kW (100kVA) | Open & Enclosed Unit
DESCRIPTION
Key Features
Engine & Performance:
- GM 5.7L Turbocharged V-8 Engine with 124.07 gross horsepower.
- Rated at 80kW with a standby power output of 100 kVA.
- Isochronous governor for ±0.50% speed regulation to ensure stable power delivery.
- Operates at 1800 RPM for optimal efficiency and durability.
Fuel Efficiency:
- Exclusively designed for Natural Gas (NG) fuel type.
- Low fuel consumption even at full load, ensuring cost efficiency:
- 100% Load: 1185 CFH (33.6 m³/hr)
- 75% Load: 981 CFH (27.8 m³/hr)
Durability:
- Heavy-duty steel base with vibration isolators for enhanced stability.
- Factory powder coating for excellent resistance to environmental factors.
- High ambient unit-mounted radiator for consistent cooling performance.
Maintenance-Friendly:
- Oil drain valve with an extension for easy servicing.
- Includes battery rack and cables for user convenience.
- Comprehensive owner’s manual for guidance.
Control Panels:
- Multiple options, including:
- DeepSea 7310 MKII: Simultaneous RS232 & RS485 communication, IP65 rated.
- Basler DGC2020: NFPA 110 Level 1 compatibility and Modbus RS485 support.
- Taylor Analog: Simplified operation with oil pressure, water temp, and battery voltage gauges.
Alternator Options:
-
Marathon PMG Alternator:
- Voltage Regulation: 0.25%
- NEMA Class N Insulation.
-
Stamford PMG Alternator:
- Voltage Regulation: 0.50%
- NEMA Class H Insulation.
Certifications & Protections:
- Certifications: ETL Certified to UL2200, CE, CSA, and EPA compliant.
Protection Features:
- Overvoltage and under-frequency safeguards.
- Over-excitation protection.
- Built to handle overspeeds up to 125%.
| Control Panels | Feature | Description |
 |
DeepSea 7310 MKII | Simultaneous Use of RS232 & RS485, Modbus RTU Support, Fully Configurable Using USB, RS232 &RS485, IP65 Rating 6 Programmable Inputs & 8 Outputs UL & cUL Listed and CE Certified |
 |
Basler DGC2020 | SAE J1939 Engine ECU, Communications, 4 Programmable Inputs & 10 Outputs Modbus Communications With RS485 UL Recognized, CSA & CE Certified IP 54 Front Panel Rating NFPA 110 Level 1 Compatible Manual Override Keyswitch DGC2020HD Variant Available |
 |
Taylor Analog | Automatic CANBUS Engine Control Gauge Zeroing on Shutdown Auto-Off-Manual Control Switch Oil Pressure, Water Temperature, Battery Voltage and RPM Gauges AC Voltage, Frequency, Percent of Load, and Run-Time Metering LED Status Lights |
Detailed Specifications
| Category | Specification |
|---|---|
| Engine | GM 5.7L Turbocharged V-8, 4-Cycle |
| Horsepower | 124.07 HP |
| Power Output | 80 kW / 100 kVA |
| Fuel Type | Natural Gas (NG) |
| Rated RPM | 1800 |
| Compression Ratio | 9.1:1 |
| Displacement | 5.7 L (350.0 in³) |
| Bore & Stroke | Bore: 101.60 mm (4.00 in) / Stroke: 88.4 mm (3.48 in) |
| Cooling Capacity | 2.1 gal (7.8 L) |
| Oil Capacity | 5.0 qt (4.7 L) |
| Air Flow Requirements | Combustion: 243.7 CFM (Radiator: 5,500 CFM) |
| Exhaust Temp | 1200°F (649°C) |
| Fuel Supply Size | 1.25” NPT |
| Fuel Pressure | 7-11 in. H₂O (1.74-2.74 kPa) |
| Voltage Regulation | Marathon PMG: 0.25% / Stamford PMG: 0.50% |
| Alternator Options | Marathon or Stamford PMG |
| Exhaust Outlet Size | 4.0 in (101.6 mm) |
| Control Panels | DeepSea 7310 MKII, Taylor Analog, Basler DGC2020 |
| Certifications | UL2200, CE, CSA, EPA |
 |
Open Unit | Overall Size: 78”L x 36”W x 50”H Approximate Weight: 2,000 lbs. |
 |
Standard Enclosed Unit | Overall Size: 120”L x 52”W x 64”H Approximate Weight: 3,700 lbs. |
