The Taylor TG800 generator delivers an impressive 800kW of standby power, making it a powerhouse solution for industrial, commercial, and mission-critical environments. Engineered to operate seamlessly on Natural Gas (NG) or Liquid Propane (LP), this generator combines a turbocharged V-12 engine, cutting-edge alternators, and advanced controls. Its UL2200 certification ensures safety, durability, and compliance with international standards.
Taylor Power System Standby-NG/LP Generator | Model TG-800 | Horsepower 1234 HP | Power Output 800kW (1000kVA) | Open & Enclosed Unit
Taylor Power System Standby-NG/LP Generator | Model TG-800 | Horsepower 1234 HP | Power Output 800kW (1000kVA) | Open & Enclosed Unit
Regular price
$1.00
Regular price
Sale price
$1.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
How To Request A Quote
***Online pricing not available, Please request a quote:***
How To Get A Quote:
Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!
Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!
Product Description
Taylor Power System Standby-NG/LP Generator | Model TG-800 | Horsepower 1234 HP | Power Output 800kW (1000kVA) | Open & Enclosed Unit
DESCRIPTION
Key Features
-
Exceptional Power Output:
- Turbocharged V-12, 4-Cycle Engine, delivering robust 800kW of power.
- Smooth operation with ±0.50% speed regulation, ensuring stability under diverse loads.
- Operates at 1800 RPM, offering consistent and efficient performance.
-
Dual Fuel Flexibility:
- Designed to run on Natural Gas (NG) or Liquid Propane (LP) fuels.
- Engineered for efficiency and reliability across varying operating conditions.
-
Durability and Stability:
- Heavy-duty steel base with vibration isolators, reducing noise and enhancing longevity.
- High ambient radiator for advanced cooling capabilities during extended operations.
- Powder-coated exterior for superior protection against wear and corrosion.
-
Advanced Control Systems:
-
Features multiple options for user-friendly monitoring and system control:
- DeepSea 7310 MKII: IP65-rated with Modbus RTU capabilities.
- Basler DGC2020: Fully programmable with advanced system monitoring.
- Taylor Analog: Simplified design with key operational indicators.
-
Features multiple options for user-friendly monitoring and system control:
-
Precision Alternators:
-
Fitted with high-efficiency alternators:
- Marathon PMG: Voltage regulation at 0.25% for Three Phase.
- Stamford PMG: Voltage regulation at 1.0% for Single Phase and 0.50% for Three Phase.
-
Fitted with high-efficiency alternators:
-
Certifications and Safety:
- Certified to UL2200, EPA, CE, and CSA standards.
- Safety measures include over-voltage, under-frequency, and over-excitation protections.
| Control Panels | Feature | Description |
 |
DeepSea 7310 MKII | Simultaneous Use of RS232 & RS485, Modbus RTU Support, Fully Configurable Using USB, RS232 &RS485, IP65 Rating 6 Programmable Inputs & 8 Outputs UL & cUL Listed and CE Certified |
 |
Basler DGC2020 | SAE J1939 Engine ECU, Communications, 4 Programmable Inputs & 10 Outputs Modbus Communications With RS485 UL Recognized, CSA & CE Certified IP 54 Front Panel Rating NFPA 110 Level 1 Compatible Manual Override Keyswitch DGC2020HD Variant Available |
 |
Taylor Analog | Automatic CANBUS Engine Control Gauge Zeroing on Shutdown Auto-Off-Manual Control Switch Oil Pressure, Water Temperature, Battery Voltage and RPM Gauges AC Voltage, Frequency, Percent of Load, and Run-Time Metering LED Status Lights |
Detailed Specification
Taylor TG800 Generator:
| Category | Specification |
|---|---|
| Manufacturer | PSI |
| Model | 39.2L |
| Aspiration | Turbocharged |
| Arrangement | V-12, 4-Cycle |
| Firing Order | 1-8-5-10-3-7-6-11-2-9-4-12 |
| Displacement | 39.2 L (2392.1 in³) |
| Bore | 150.00 mm (5.91 in) |
| Stroke | 185.00 mm (7.28 in) |
| Compression Ratio | 10.5:1 |
| Gross Horsepower | 1234 HP |
| BMEP | 227 psi (1565 kPa) |
| Rated RPM | 1800 |
| Governor | Isochronous |
| Speed Regulation | ±0.50% |
| Oil System Capacity | 154 qt (146 L) |
| Cooling Capacity | 43.4 gal (164.1 L) |
| Electric Volts | DC 24 |
| Cold Cranking Amps | 1100 |
| Battery(s) Required | 2 |
| Fuel Supply Size | (2) 3.00” NPT |
| Supply Pressure | 20-30 in. H₂O (4.98-7.47 kPa) |
| Air Filter(s) Type | Dry |
| Combustion Air Flow | 1591 CFM (45 m³/min) |
| Max Air Intake Restriction (Clean) | 5.2 in. H₂O (1.3 kPa) |
| Max Air Intake Restriction (Dirty) | 15.00 in. H₂O (3.74 kPa) |
| Radiator Air Flow | 52,000 CFM (1472 m³/min) |
| Exhaust Gas Temperature | 1238°F (670°C) |
| Exhaust Gas Flow | 4920 CFM (139 m³/min) |
| Max Back Pressure | 51.71 in. H₂O (12.87 kPa) |
| Air Cleaner Quantity | 2 |
| Oil Filter(s) Quantity | 1 |
| Fuel Consumption @ 100% Power | 10109 CFH (286 m³/hr) |
| Fuel Consumption @ 75% Power | 7503 CFH (212 m³/hr) |
| Fuel Consumption @ 50% Power | 5410 CFH (153 m³/hr) |
| Fuel Consumption @ 25% Power | 3468 CFH (98 m³/hr) |
