TecnoGen Enermax Series 8kW 10kVA KL10MSX Generator

SPECIFICATION

• PRIME POWER: 8 kW
• SOUND LEVEL @ 23': 67 DBA
• CONTROLLER: Deep Sea
• ALTERNATOR: Leroy Somer
• ENGINE MODEL: Kohler KDW1404
• EPA LEVEL: Tier 4F
• HORSEPOWER: 16.7
• FUEL CAPACITY: 49 Gallons
• RUN TIME @ 75%: 70 Hours
• LENGTH: 69"
• WIDTH: 30"
• HEIGHT: 49"
• WEIGHT: 1,244 lbs

AMPS

• Single Phase 120V zz: 41x2 zz
• Single Phase 240V: 41

GENERAL ENGINE DATA

• Engine brand: Kohler
• Engine model: KDW1404
• EPA LEVEL TIER4 FINAL
• Cylinders: 4
• R.P.M: 1800
• Gross Horse power:  14
• External fuel Valve: Yes
• Fuel Containment: 110%

FUEL CONSUMPTION

• Fuel Type: Diesel
• Fuel Capacity gal: 49
• Fuel Cons. at 75% (P.R.P.):  0,7
• Run Time @ 75%: 70

ALTERNATOR DATA

• Alternator brand: Leroy Somer
• Alternator model: LSA 40S3
• P.R.P. Power: kVA 13
• L.T.P. Power kVA: 14,5
• IP Protection 23
• Voltage regulator: ±0,25% AREP
• Short-circuit current: 300 %: 10s

WEIGHTS AND DIMENSIONS SKID WITH TRAILER

• Length: 101 inch
• Width: 63 inch
• Height: 65 inch
• Dry weight: 1282
• Wet weight lbs. 1424

WEIGHTS AND DIMENSIONS SKID WITHOUT TRAILER

• Length: 69 inch
• Width: 30 inch
• Height: 49 inch
• Dry weight: 1102
• Wet weight lbs. 1244

SUPERIOR PERFORMANCE

The Enermax Series has the features you want standard with the largest range of prime power in its class.

CUSTOMER FOCUSED

With TecnoGen, you’ll always get a commitment to superior service, fast turnaround times and real 24/7 support.

OVERBUILT BY TECNOGEN

Perfect for the construction, industrial and rental sectors, TecnoGen designed the Enermax Series to make it the most innovative, reliable and rugged power machine on the market.
