Product Description
TTA SP9-VTOL Long Range Drone | Fixed-Wing & Multirotor Hybrid | 2kg Payload Capacity, 4-5 Hour Flight Endurance | 20km Range
DESCRIPTION
The TTA SP9-VTOL Long Range Drone combines the best of fixed-wing efficiency with the versatility of a multirotor, offering unmatched aerial capabilities for long-duration and extensive-range applications. Designed for tasks such as aerial surveying and reconnaissance, the SP9-VTOL operates for 4 to 5 hours without payload, thanks to its optimized design and lightweight fiberglass frame. This drone offers a payload capacity of up to 2 kg, making it perfect for carrying high-grade surveying equipment or additional sensors.
With the SP9-VTOL’s 20km data communication range, operators benefit from extensive reach, ideal for covering vast survey areas or monitoring large fields. The GPS-enabled flight control system and data communication module ensure stability and accuracy over long distances, while the included ground station software provides real-time flight monitoring. The rugged frame and the innovative hybrid VTOL design make this drone an asset for professional aerial operations where reliability and endurance are key.
Key Features
- Hybrid Design: Combines fixed-wing and multirotor functions for optimal efficiency and control.
- Long Flight: Offers up to 5 hours of flight time without payload.
- High Payload: Capable of carrying up to 2 kg for various equipment needs.
- Extended Range: Communication range of up to 20 km for long-distance missions.
- Durable Build: Made of high-quality fiberglass, ensuring lightweight durability.
- Advanced GPS: Equipped with GPS-enabled flight control for precision and stability.
- Data Communication: Real-time data module provides long-range control.
- Easy Operation: User-friendly system with redundancy in control systems.
- Comprehensive Support: Includes US-based technical support and warranty service.
- Portable: Comes with a transport case and assembly tools for easy transport.
Detailed Specifications
| Feature | Details |
|---|---|
| Length | 1770 mm |
| Frame Material | Fiberglass |
| Color | White |
| Payload Capacity | ≤2 kg |
| Flight Time (No Payload) | 4-5 hours |
| Usage | Aerial Surveying |
| Data Communication Range | Up to 20 km |
| Battery Requirement | 2 x 22.8V 25000mAh (not included) |
| Flight Control System | GPS-enabled with redundancy |
| Control System | Handheld Radio Controller |
In the Package
- TTA SP9-VTOL UAV with autopilot, fully tested
- Handheld Radio Controller
- GPS-Enabled Flight Control System with redundancy
- Data Communication Module (up to 20 km)
- Ground Station Software (tablet not included)
- Transport Case
- Assembly Tools
- Spare Parts Kit
- Operator’s E-Manual
Available Options
- Extended Warranty: Additional coverage for prolonged support.
- Battery & Charger Kit: Requires 2 x 22.8V 25000mAh batteries per flight (not included).
- Custom Payload Mounts: To support specific equipment needs.
- Additional Ground Station Software License: For multi-device or multi-user access.
