Venture 3/8 Special Skid Steer Mounted Grout Pump (SSU) With Cavity Pump | Hopper Fill Height 30" | For Skid Steer
DESCRIPTION
Skid Steer Mounted pump designed for Small Rock, Concrete and Grout Applications, Designed for powerful performance and rugged reliability. Depend on the SSU to pump a variety of materials and tackle difficult applications with ease. To fit your project, accessories such as, hoses, couplings, spray nozzles, clamps, reducers can be added. Designed for safe and simple operation, Easy clean up and low maintenance.
Key Features
- Progressive Cavity Pump: Ensures consistent material flow
- Hopper Capacity: 8 cubic foot (225L) for ample material storage
- High Output Rate: 10-12 yards/hour (9 cubic meters)
- Heavy-Duty Output: 4” HD output (101mm) for robust delivery
- Hydraulic Efficiency: Minimum hydraulic flow rate of 15 GPM @ 2500 PSI
Detailed Specifications
| Feature | Specification |
|---|---|
| Pump Type | Progressive Cavity Pump |
| Hopper Capacity | 8 Cubic Feet (225L) |
| Output Rate | 10-12 Yards/Hour (9 Cubic Meters) |
| Output Diameter | 4” HD (101mm) |
| Maximum Aggregate Size | 3/8” Pea Gravel (10mm) |
| Weight | 885 lbs |
| Hopper Fill Height | 30” |
| Minimum Hydraulic Flow Rate | 15 GPM @ 2500 PSI |
Application
- Masonry Grouts
- SCC (Self-Consolidating Concrete)
- Pour & Form
- 3D Concrete Printing
- Shotcrete
- Epoxy Grout
- Abandoned utility grouting
- Slurry
- Light-weight Concrete
- 3/8″ Ready Mix Concrete
Manuals & Documents
3/8 SSU MANUAL
