Werk-Brau Angle Broom | Model WHLP | Width 72"–96" | 8–45 GPM | 8–45 Tons | For Backhoes

Werk-Brau Angle Broom | Model WHLP | Width 72"–96" | 8–45 GPM | 8–45 Tons | For Backhoes

Regular price $1.00
Regular price Sale price $1.00
Sale Sold out
Machine Compatibility
Customizable
Fast
24/7 Support
  • Pricing Unavailable, Request Quote
  • Broom Width: Available in 72" and 96" configurations.
  • Hydraulic Flow: Supports 8–45 GPM flow configurations.
  • Brush Diameter: Features a durable 32" diameter brush.
  • Machine Compatibility: Designed for 8–45 ton backhoe applications.
  • Intended Use: Clears snow, dirt, debris, and surfaces.
View full details

How To Request A Quote

***Online pricing not available, Please request a quote:***

How To Get A Quote:

Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!

Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!

Product Description

Werk-Brau Angle Broom | Model WHLP | Width 72"–96" | 8–45 GPM | 8–45 Tons | For Backhoes


DESCRIPTION

The Werk-Brau Backhoe Angle Broom (WHLP) is a hydraulic angle broom engineered for efficient snow, dirt, debris, and surface cleanup on backhoe applications. Designed for commercial-duty performance, it combines a rugged frame, high-strength broom housing, and floating broom design to maintain consistent ground contact across changing surface contours. The 32" diameter refillable brush core and broom speeds up to 200 RPM support productive sweeping, while hydraulic angle adjustment up to 30° left or right helps operators direct material without repeated repositioning. Heavy-duty 10" swivel casters, self-aligning greaseable bearings, and a hydraulic brush-lift cylinder improve maneuverability and control. Available in 72" and 96" widths, with single- or dual-motor configurations for 8–45 GPM hydraulic systems, this broom offers versatile compatibility for backhoes and selected loader applications.

Key Features

  • Hydraulic Angle Control: Adjusts the broom up to 30° left or right, allowing operators to direct snow, dirt, and debris efficiently while reducing the need for repeated machine repositioning during cleanup operations.
  • Heavy-Duty Commercial Construction: Built with a rugged tubular cross-member, formed brush arms, reinforced housing, and durable steel components to withstand demanding site cleanup and surface maintenance applications.
  • 72" and 96" Width Options: Available in practical 6-foot and 8-foot broom widths, providing flexible coverage for different machine sizes and cleanup requirements while maintaining efficient sweeping productivity.
  • 32" Diameter Brush: Features a large 32" diameter broom core with refillable flat wafers, providing effective contact with surfaces for clearing dirt, snow, debris, and other loose materials.
  • Up to 200 RPM Brush Speed: Hydraulic drive delivers broom speeds of up to 200 RPM, helping operators achieve efficient material collection and movement across a wide range of cleanup surfaces.
  • Floating Broom Design: Parallel upper and lower arms allow the broom to float and follow surface contours, helping maintain consistent ground contact and improving sweeping results across uneven surfaces.
  • Heavy-Duty Swivel Casters: Two 10" 360° swivel casters support smooth movement and help maintain proper broom positioning while reducing unnecessary load on the attachment during sweeping operations.
  • Hydraulic Brush Lift: A dedicated cylinder with 8" stroke and 2" bore provides controlled brush lifting, making it easier to position the attachment for transport, maneuvering, and sweeping operations.
  • Flexible Hydraulic Motor Options: Configurations include single and dual hydraulic motors designed for different flow requirements, supporting machines from approximately 8 to 45 GPM depending on broom width and configuration.
  • Low-Flow Compatibility: Optional low-flow motor configurations accommodate hydraulic systems operating at 8–11 GPM, 15–24 GPM, helping expand compatibility across various backhoe and loader hydraulic systems.
  • Durable Brush Housing: The broom hood provides approximately 155° of brush coverage and incorporates formed edges and end plates for added structural strength and protection during repeated use.
  • Easy Broom Removal: The refillable broom core can be removed without disconnecting hydraulic hoses, simplifying maintenance and reducing downtime during brush replacement or servicing.
  • Multiple Mounting Options: Supports loader mounting kits, quick coupler mounting, and pin-on mounting frames, providing flexibility for different machine configurations and attachment requirements.
  • Optional Sprinkler System: A 45-gallon sprinkler system is available to help control dust during sweeping operations, making the broom suitable for construction sites, roads, yards, and other dusty environments.
  • Protective Factory Finish: Steel surfaces receive a phosphatizing acid treatment, followed by epoxy primer and polyurethane topcoat to provide a durable gray finish suitable for demanding outdoor operating conditions.

Detailed Specifications

Specification 72" Standard Single Motor 72" Optional Dual Motor
Brand Werk-Brau Werk-Brau
Model WHLP WHLP
Broom Width 72" 72"
Attachment Type Hydraulic Backhoe Angle Broom Hydraulic Backhoe Angle Broom
Recommended Machine Class 8–45 Tons 8–45 Tons
Hydraulic Motor Single Motor Dual Motor
Hydraulic Flow 12–20 GPM 25–45 GPM
Low-Flow Option 8–11 GPM 15–24 GPM
Brush Diameter 32" 32"
Maximum Brush Speed Up to 200 RPM Up to 200 RPM
Hydraulic Angle 30° Left / 30° Right 30° Left / 30° Right
Swing Method Manual or Electric/Hydraulic Manual or Electric/Hydraulic
Brush Lift Cylinder 2" Bore × 8" Stroke 2" Bore × 8" Stroke
Brush Core Refillable Flat-Wafer Core Refillable Flat-Wafer Core
Brush Material Poly/Wire Options Poly/Wire Options
Brush Hood Coverage 155° 155°
Caster Configuration Two 10" Heavy-Duty Swivel Casters Two 10" Heavy-Duty Swivel Casters
Caster Rotation 360° 360°
Bearing Type Self-Aligning Greaseable Pillow Block Self-Aligning Greaseable Pillow Block
Frame Cross-Member 3-1/2" O.D. Tubular 3-1/2" O.D. Tubular
Brush Arm Construction 1/4" Plate 1/4" Plate
Storage Stands Standard Standard
Sprinkler Option 45-Gallon 45-Gallon
Dirt Deflector Optional Optional
Sight Indicators Optional Optional
Independent Hydraulic System Optional Optional
Finish Gray Gray


Specification 72" Low-Flow Single Motor 72" Dual Low-Flow Motor
Brand Werk-Brau Werk-Brau
Model WHLP WHLP
Broom Width 72" 72"
Attachment Type Hydraulic Backhoe Angle Broom Hydraulic Backhoe Angle Broom
Recommended Machine Class 8–45 Tons 8–45 Tons
Hydraulic Motor Single Motor Dual Low-Flow Motor
Hydraulic Flow 8–11 GPM 15–24 GPM
Brush Diameter 32" 32"
Maximum Brush Speed Up to 200 RPM Up to 200 RPM
Hydraulic Angle 30° Left / 30° Right 30° Left / 30° Right
Swing Method Manual or Electric/Hydraulic Manual or Electric/Hydraulic
Brush Lift Cylinder 2" Bore × 8" Stroke 2" Bore × 8" Stroke
Brush Core Refillable Flat-Wafer Core Refillable Flat-Wafer Core
Brush Material Poly/Wire Options Poly/Wire Options
Brush Hood Coverage 155° 155°
Casters Two 10" Heavy-Duty Two 10" Heavy-Duty
Caster Rotation 360° Swivel 360° Swivel
Bearing Type Self-Aligning Greaseable Pillow Block Self-Aligning Greaseable Pillow Block
Storage Stands Standard Standard
Sprinkler System Optional 45-Gallon Optional 45-Gallon
Dirt Deflector Optional Optional
Sight Indicators Optional Optional
Finish Gray Gray


Specification 96" Standard Dual Motor 96" Low-Flow Dual Motor
Brand Werk-Brau Werk-Brau
Model WHLP WHLP
Broom Width 96" 96"
Attachment Type Hydraulic Backhoe Angle Broom Hydraulic Backhoe Angle Broom
Recommended Machine Class 8–45 Tons 8–45 Tons
Hydraulic Motor Dual Motor Dual Low-Flow Motor
Hydraulic Flow 25–45 GPM 15–24 GPM
Brush Diameter 32" 32"
Maximum Brush Speed Up to 200 RPM Up to 200 RPM
Hydraulic Angle 30° Left / 30° Right 30° Left / 30° Right
Swing Method Manual or Electric/Hydraulic Manual or Electric/Hydraulic
Brush Lift Cylinder 2" Bore × 8" Stroke 2" Bore × 8" Stroke
Brush Core Refillable Flat-Wafer Core Refillable Flat-Wafer Core
Brush Material Poly/Wire Options Poly/Wire Options
Brush Hood Coverage 155° 155°
Casters Two 10" Heavy-Duty Swivel Two 10" Heavy-Duty Swivel
Caster Rotation 360° 360°
Bearing Type Self-Aligning Greaseable Pillow Block Self-Aligning Greaseable Pillow Block
Frame Cross-Member 3-1/2" O.D. Tubular 3-1/2" O.D. Tubular
Brush Arm Construction 1/4" Plate 1/4" Plate
Storage Stands Standard Standard
Sprinkler Option 45-Gallon 45-Gallon
Dirt Deflector Optional Optional
Sight Indicators Optional Optional
Independent Hydraulic System Optional Optional
Finish Gray Gray
