Werk-Brau Angle Broom | Model WTKH-L | Width 96–144" | 16–60 GPM | For Wheel Loaders

Werk-Brau Angle Broom | Model WTKH-L | Width 96–144" | 16–60 GPM | For Wheel Loaders

$1.00
$1.00
Sale Sold out
Machine Compatibility
Customizable
Fast
24/7 Support
  • Pricing Unavailable, Request Quote
  • Broom Width: 96", 120", & 144".
  • Hydraulic Flow: 16–60 GPM.
  • Brush Diameter: 32" O.D. × 10" I.D.
  • For Wheel Loaders with Hydraulic Drive Systems.
  • Ideal for Snow, Dirt, Debris, Road Maintenance.
View full details

How To Request A Quote

***Online pricing not available, Please request a quote:***

How To Get A Quote:

Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!

Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!

Product Description

Werk-Brau Angle Broom | Model WTKH-L | Width 96–144" | 16–60 GPM | For Wheel Loaders


DESCRIPTION

The Werk-Brau WTKH-L Wheel Loader Angle Broom is a heavy-duty hydraulic angle broom engineered for efficient snow, dirt, debris, and material cleanup across demanding job sites. Available in 96", 120", and 144" widths, it delivers broad sweeping coverage while hydraulic swing capability lets operators direct material 30° left or right without repositioning the loader. The broom features a 32" O.D. × 10" I.D. wafer-style brush, quick-change brush core, and dual low-speed, high-torque hydraulic motors for consistent sweeping performance. Built with a reinforced steel frame, 16-gauge hood, 12-gauge end plates, and solid rubber casters, the WTKH-L is designed for commercial-duty operation, road maintenance, site cleanup, and material control. Multiple loader mounting configurations and brush-drive options support versatile equipment compatibility.

Key Features

  • Hydraulic Angle Adjustment Swing the broom 30° left or right to direct snow, dirt, and debris where needed without repositioning the wheel loader.
  • Heavy-Duty Hydraulic Drive Dual low-speed, high-torque 18 CID hydraulic motors provide dependable broom rotation for demanding cleanup applications.
  • Wide Sweeping Coverage Choose 96", 120", or 144" broom widths to match the loader and efficiently cover large areas.
  • High-Torque Brush Performance Hydraulic motors are directly coupled to the brush core through a 5-5/16" poly hexagonal hub for effective power transfer.
  • Quick-Change Brush Core Removable brush and core assembly simplifies maintenance and replacement without disconnecting hydraulic hoses.
  • Commercial-Duty Construction Reinforced frame components and heavy-gauge steel construction support continuous use in demanding work environments.
  • 32-Inch Wafer Brush The 32" O.D. × 10" I.D. brush provides substantial contact area for effective surface sweeping.
  • Adjustable Brush Pattern An adjustable link compensates for brush wear, helping maintain an effective sweeping pattern during service life.
  • Protected Hydraulic Motors Recessed motor placement helps protect the hydraulic drive components from accidental collision and job-site impacts.
  • Heavy-Duty Brush Hood 16-gauge steel hood with formed-edge reinforcement and 12-gauge end plates provide added structural strength.
  • Maneuverable Caster System Two 16½" × 8" solid rubber casters provide 360° maneuverability and support smooth broom operation.
  • Easy Mounting & Storage Integrated storage stands simplify attachment mounting, dismounting, and storage between jobs.
  • Multiple Coupler Options Available mounting configurations support ACS Pro 2000, CAT Fusion, JRB, Volvo, CAT IT, Euro, and pin-on connections.
  • Flexible Hydraulic Configurations Available low-flow and high-flow motor configurations support different loader hydraulic systems and operating requirements.
  • Optional Cleanup Equipment Configure the broom with spray bars, sprinkler systems, deflectors, flotation systems, or an oil cooler for specialized applications.

Detailed Specifications

Specification 96" Model 120" Model
Brand Werk-Brau Werk-Brau
Model Series WTKH-L WTKH-L
Attachment Type Hydraulic Wheel Loader Angle Broom Hydraulic Wheel Loader Angle Broom
Broom Width 96" 120"
Recommended Machine Wheel Loader Wheel Loader
Hydraulic Drive Dual Hydraulic Motors Dual Hydraulic Motors
Standard Hydraulic Flow 28–40 GPM 28–40 GPM
Low-Flow Option 16–24 GPM 16–24 GPM
High-Flow Option 40–60 GPM 40–60 GPM
Motor Type Low-Speed, High-Torque Low-Speed, High-Torque
Standard Motor Size 18 CID × 2 18 CID × 2
Maximum Brush Speed Up to 250 RPM* Up to 250 RPM*
Hydraulic Swing 30° Left / 30° Right 30° Left / 30° Right
Brush Diameter 32" O.D. 32" O.D.
Brush Inside Diameter 10" I.D. 10" I.D.
Brush Type Wafer Style Wafer Style
Brush Material Polypropylene & Wire Polypropylene & Wire
Brush Core Quick-Change Quick-Change
Brush Core Installation Reversible Left/Right Reversible Left/Right
Brush Hub 5-5/16" Poly Hexagonal 5-5/16" Poly Hexagonal
Brush Frame Cross Member 3½" O.D. Round Tubular Steel 3½" O.D. Round Tubular Steel
Brush Arms ¼" Steel Plate ¼" Steel Plate
Front Support Bar Rectangular Steel Rectangular Steel
Brush Hood 16-Gauge Steel 16-Gauge Steel
Hood End Plates 12-Gauge Steel 12-Gauge Steel
Caster Quantity 2 2
Caster Size 16½" × 8" 16½" × 8"
Caster Type Solid Rubber Solid Rubber
Caster Rotation 360° 360°
Caster Stem 2" O.D. Sealed & Greaseable 2" O.D. Sealed & Greaseable
Motor Protection Recessed in Brush Frame Recessed in Brush Frame
Storage Stands Standard Standard
Sight Indicator Flags Standard Standard
Hydraulic Hoses Drive Motor to Bulkhead/Valve Drive Motor to Bulkhead/Valve
Prime-Mover Hoses Customer Supplied Customer Supplied
Mounting Options Multiple Coupler Configurations Multiple Coupler Configurations
Surface Finish Phosphatized, Epoxy Primer & Polyurethane Phosphatized, Epoxy Primer & Polyurethane
Standard Color Gray Gray
Optional Deflector Available Available
Optional Spray Bar Available Available
Optional Sprinkler System 90-Gallon System Available 90-Gallon System Available
Optional Flotation System Parallel Arm Available Parallel Arm Available
Optional Oil Cooler Available, 40 GPM Max Available, 40 GPM Max


Specification 144" Model
Brand Werk-Brau
Model Series WTKH-L
Attachment Type Hydraulic Wheel Loader Angle Broom
Broom Width 144"
Recommended Machine Wheel Loader
Hydraulic Drive Dual Hydraulic Motors
Standard Hydraulic Flow 28–40 GPM
Low-Flow Option 16–24 GPM
High-Flow Option 40–60 GPM
Motor Type Low-Speed, High-Torque
Standard Motor Size 18 CID × 2
Maximum Brush Speed Up to 250 RPM*
Hydraulic Swing 30° Left / 30° Right
Brush Diameter 32" O.D.
Brush Inside Diameter 10" I.D.
Brush Type Wafer Style
Brush Material Polypropylene & Wire
Brush Core Quick-Change
Brush Core Installation Reversible Left/Right
Brush Hub 5-5/16" Poly Hexagonal
Brush Frame Cross Member 3½" O.D. Round Tubular Steel
Brush Arms ¼" Steel Plate
Front Support Bar Rectangular Steel
Brush Hood 16-Gauge Steel
Hood End Plates 12-Gauge Steel
Caster Quantity 2
Caster Size 16½" × 8"
Caster Type Solid Rubber
Caster Rotation 360°
Caster Stem 2" O.D. Sealed & Greaseable
Motor Protection Recessed in Brush Frame
Storage Stands Standard
Sight Indicator Flags Standard
Hydraulic Hoses Drive Motor to Bulkhead/Valve
Prime-Mover Hoses Customer Supplied
Mounting Options Multiple Coupler Configurations
Surface Finish Phosphatized, Epoxy Primer & Polyurethane
Standard Color Gray
Optional Deflector Available
Optional Spray Bar Available
Optional Sprinkler System 90-Gallon System Available
Optional Flotation System Parallel Arm Available
Optional Oil Cooler Available, 40 GPM Max
