Werk-Brau

Werk-Brau Skeleton Rock Loader Bucket | Width 100" To 124" | 2.00–5.50 yd³ | 15–40 GPM | For Wheel Loaders

Werk-Brau Skeleton Rock Loader Bucket | Width 100" To 124" | 2.00–5.50 yd³ | 15–40 GPM | For Wheel Loaders

Regular price $1.00
Regular price Sale price $1.00
Sale Sold out
Machine Compatibility
Customizable
Fast
24/7 Support
  • Pricing Unavailable, Request Quote
  • Bucket Width: 100–124".
  • Edge Length: 102–126".
  • Hydraulic Flow: 15–40 GPM.
  • Loader Classes: 1–5 Wheel Loaders.
  • For Quarry Rock, Debris Sifting, Material Handling.
View full details

How To Request A Quote

***Online pricing not available, Please request a quote:***

How To Get A Quote:

Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!

Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!

Product Description

Werk-Brau Skeleton Rock Loader Bucket | Width 100" To 124" | 2.00–5.50 yd³ | 15–40 GPM | For Wheel Loaders


DESCRIPTION

The Werk-Brau Skeleton Rock Bucket is a heavy-duty wheel loader attachment engineered for quarry work, rock handling, and applications requiring efficient material separation. Its open tine design allows loose rock and larger material to be loaded while finer debris and unwanted material fall through, helping keep loads lighter and more manageable. Built from high-strength steel, the bucket provides durability and long wear life in demanding abrasive environments. Reinforced side plates withstand heavy-duty loading impacts, while the replaceable bolt-on cutting edge with a heavy-duty GET system supports productive loading operations. Available in 100" to 124" widths with 2.00 to 5.50 yd³ struck capacities, it can be configured with a Werk-Brau front coupler or pin-up connection. Hydraulic requirements range from 15 to 40 GPM, depending on the loader configuration.

Key Features

  • Heavy-Duty Steel Tines Built with high-strength steel tines to withstand demanding wheel loader, quarry, rock handling, and abrasive material applications.
  • Open Tine Design Allows finer debris and loose material to fall through during loading, helping improve material separation, load control, and operating efficiency.
  • Reinforced Side Plates Heavy-duty reinforced side plates provide added structural strength and durability when handling rock, quarry material, and abrasive debris.
  • Replaceable Bolt-On Cutting Edge Full-width replaceable cutting edge with a heavy-duty GET system supports productive loading and simplifies cutting-edge replacement.
  • Quarry-Ready Construction Designed specifically for demanding quarry and rock handling applications, where efficient screening and material control are essential.
  • High-Strength Steel Construction Durable steel construction provides reliable performance and extended service life during heavy-duty wheel loader operations.
  • Efficient Material Screening Strategic tine spacing helps separate larger rocks from finer debris while loading and transporting material.
  • Reduced Unwanted Material Open bucket construction helps prevent excessive fines and unwanted debris from being carried with larger rock.
  • Multiple Width Options Available in several configurations from 100" to 124", helping match bucket capacity to different wheel loader requirements.
  • Large Material Capacity Rated configurations provide approximately 2.00 to 5.50 yd³ struck capacity for efficient rock and aggregate handling.
  • Flexible Tine Spacing Standard 5" rib spacing is available on several models, with special tine spacing designs available upon request.
  • Loader Coupler Compatibility Available with a Werk-Brau front coupler or pin-up connection for flexible wheel loader attachment configurations.
  • Heavy-Duty Rock Handling Engineered to efficiently move loose rock, quarry debris, and larger aggregate while controlling finer material.
  • 15–40 GPM Hydraulic Requirement Designed for wheel loader applications requiring approximately 15 to 40 GPM hydraulic flow, depending on configuration.
  • Production Loading Design Combines an open screening profile, reinforced structure, and replaceable GET cutting edge for efficient production loading.

Detailed Specifications

Specification WL1SKL100-2.00 WL2SKL100-2.50
Brand Werk-Brau Werk-Brau
Product Type Skeleton Rock Bucket Skeleton Rock Bucket
Attachment Type Wheel Loader Bucket Wheel Loader Bucket
Loader Class 1 2
Part Number WL1SKL100-2.00 WL2SKL100-2.50
Bucket Width 100" 100"
Edge Length 102" 102"
Rib Spacing 4" 5"
Struck Capacity 2.00 yd³ 2.50 yd³
Rated Capacity 2 yd³ 3 yd³
Weight Not specified in supplied data Not specified in supplied data
Hydraulic Flow Requirement 15–40 GPM 15–40 GPM
Construction High-strength steel High-strength steel
Design Open skeleton/tine design Open skeleton/tine design
Recommended Application Quarry work, loose rock, debris sifting Quarry work, loose rock, debris sifting
Cutting Edge Replaceable bolt-on cutting edge Replaceable bolt-on cutting edge
Connection Werk-Brau front coupler or pin-up Werk-Brau front coupler or pin-up



Specification WL3SKL100-3.00 WL3.5SKL105-3.50
Brand Werk-Brau Werk-Brau
Product Type Skeleton Rock Bucket Skeleton Rock Bucket
Attachment Type Wheel Loader Bucket Wheel Loader Bucket
Loader Class 3 3.5
Part Number WL3SKL100-3.00 WL3.5SKL105-3.50
Bucket Width 100" 105"
Edge Length 102" 108"
Rib Spacing 5" 5"
Struck Capacity 3.00 yd³ 3.50 yd³
Rated Capacity 3.5 yd³ 4 yd³
Weight 2,050 lb 2,400 lb
Hydraulic Flow Requirement 15–40 GPM 15–40 GPM
Construction High-strength steel High-strength steel
Design Open skeleton/tine design Open skeleton/tine design
Recommended Application Quarry work, loose rock, debris sifting Quarry work, loose rock, debris sifting
Cutting Edge Replaceable bolt-on cutting edge Replaceable bolt-on cutting edge
Connection Werk-Brau front coupler or pin-up Werk-Brau front coupler or pin-up



Specification WL4SKL117-4.50 WL5SKL124-5.50
Brand Werk-Brau Werk-Brau
Product Type Skeleton Rock Bucket Skeleton Rock Bucket
Attachment Type Wheel Loader Bucket Wheel Loader Bucket
Loader Class 4 5
Part Number WL4SKL117-4.50 WL5SKL124-5.50
Bucket Width 117" 124"
Edge Length 119" 126"
Rib Spacing 5" 5"
Struck Capacity 4.50 yd³ 5.50 yd³
Rated Capacity 4.50 yd³ 6 yd³
Weight 2,900 lb 3,600 lb
Hydraulic Flow Requirement 15–40 GPM 15–40 GPM
Construction High-strength steel High-strength steel
Design Open skeleton/tine design Open skeleton/tine design
Recommended Application Quarry work, loose rock, debris sifting Quarry work, loose rock, debris sifting
Cutting Edge Replaceable bolt-on cutting edge Replaceable bolt-on cutting edge
Connection Werk-Brau front coupler or pin-up Werk-Brau front coupler or pin-up
