Product Description
Woody Equipment 12′ Forestry Trailer Model 12-86 HV with Log Loader 150-HDT | For Tractors
Description
The Woody Equipment 12′ Forestry Trailer Model 12-86 with Log Loader 150-HDT is a robust and versatile piece of machinery designed for efficient forestry operations.
This trailer is ideal for forestry professionals looking for reliable and efficient equipment to handle their logging needs.
The 150-HDT Telescopic Log Loader model equipped with a 15' boom and a 3’ telescopic hydraulic boom extension makes it ideal for trucks and tractors from 50 HP and more. With its lift capacity that exceeds its competitors, this model is an excellent choice for the most demanding producers.
Key Features
- Heavy-Duty Construction: Built to withstand tough forestry conditions, ensuring durability and longevity.
- 12-Foot Trailer: Provides ample space for transporting logs and other materials.
- Log Loader 150-HDT: Equipped with a powerful hydraulic log loader, making it easy to lift and move heavy logs.
- Compatibility: Designed to be used with tractors, enhancing its versatility and ease of use.
-
Safety Features: Includes various safety mechanisms to ensure secure and efficient operation.
This trailer and log loader combination is ideal for forestry operations, offering a balance of durability, capacity, and versatility.
Note: Each trailer model is interchangeable with each loader model.
Detailed Specifications
Forestry Trailer
| Category | Details |
|---|---|
| Compatible with Log Loaders | Log loader 150 HD, Log loader 170 HD, Log loader 130 HD |
| DIMENSIONS | |
| Load length | 141’’ (11’ 9’') |
| Overall length | 213’’ (17’ 9’') |
| Overall Width | 83’’ |
| Gross trailer weight | 2639 lb |
| CAPACITY | |
| Axle capacity | 8000 Lb / each |
| Trailer tonnage | 8 Tons / 16000 Lb |
| Volume | 290 Cubic feet |
| Surface | 24.4 Square feet |
| Surface Wood Cords (8’ Large X 4’ High) | 0.76 Wood Cords |
| CHARACTERISTICS | |
| Protective Grid | inclusive |
| Number of posts | 8 |
| Tires | 8 ply, 11L15 |
| OPTION | |
| Gravel bin 7’ with hydraulic cylinder | 31-060 |
| Tires | 400-60-15.5 |
| Tires (used) | 385-65-22.5 |
| Articulated drawbar double cylinder | 59-076-05 |
Log Loader
| Category | 150-HDT |
|---|---|
| RECOMMENDED VEHICLE | Tractors 40 hp & more |
| Boom length | 15’ |
| 36” Telescopic boom on teflon strip | Standard on HDT model |
| Boom rotation swing | 300° |
| Loader column height | 75" |
| Lifting capacity at maximum reach | 1500 lb. / 1400 lb. |
| Lifting capacity at mid range | 3000 lb. / 2900 lb. |
| Recommended flow | 4 - 8 gpm |
| Stabilizers | Telescopic |
| Grapple open | 52" |
| Grapple close | 3" |
| Grapple rotation (continuous) | 360° |
| Rotator maximum capacity | 3000 kg. |
| Total weight (without trailer) | 2000 lb. / 2100 lb. |
| LOADER OPTION | |
| Hydraulic winch | 6000 lb. |
| Power unit (Honda) | 9 hp or 13 hp |
| Work station | Available |
| Bucket | 14" or 18" |
