Product Description
Woody Equipment 8' 9'' Forestry Trailer Model 9-58 HV with Log Loader 105 HD | For Compact Tractors 20 HP - 40HP
Description
Woody Equipment is proud to present our new 9-58 HV forestry trailer. This innovative design lowers the center of gravity, allowing for more wood to be transported safely and efficiently. The trailer is compatible with both the 95HD and 105HD log loaders, offering flexibility and versatility for various forestry tasks.
This combination of the 9-58 HV trailer and the 105-HD Log Loader is ideal for those looking to maximize their efficiency and productivity in forestry operations. Whether you’re transporting logs or performing other forestry tasks, this equipment is designed to meet your needs with reliability and ease
The 105-HD Woody Log Loader is a versatile loader that is both lightweight and powerful. With its low profile height and a boom reach 10' 6", this loader will help you perform multiple jobs both in the sugar bush and forest. Designed specifically for 20 - 40 HP tractor.
Key Features
- Compatibility: Designed for compact tractors with 20 HP to 40 HP.
- Boom Length: 10’6" for extended reach.
- Boom Rotation Swing: 270° for versatile maneuverability.
- Loader Column Height: 53" for optimal loading height.
-
Lifting Capacity:
- At maximum reach: 650 lb.
- At mid-range: 1,300 lb.
- Recommended Flow: 3 - 4 gpm for efficient hydraulic operation.
- Stabilizers: Telescopic for enhanced stability during operation.
-
Grapple:
- Open: 28"
- Close: 3"
- Rotation (Continuous): 360° for full rotation capability.
- Rotator Maximum Capacity: 1,000 kg for heavy-duty lifting.
- Total Weight: 850 lb. (without trailer and hydraulic power unit).
-
Loader Options:
- Hydraulic Winch: Available in 4,000 lb. and 6,000 lb. capacities.
- Power Unit (Honda): 5.5 hp for reliable power.
- Bucket Sizes: 14" or 18" for different loading needs.
This forestry trailer and log loader combination is ideal for those needing a robust and versatile solution for their forestry tasks.
Product Specifications
Forestry Trailer
| Category | Details |
|---|---|
| Compatible with log loaders | log loader 95 HD, log loader 105 HD |
| DIMENSIONS | |
| Load length | 105’’ (8’ 9’') |
| Overall length | 174’’ (14’ 6’') |
| Overall Width | 58’’ |
| Gross trailer weight | 1642 lb |
| CAPACITY | |
| Axle capacity | 3500 Lb / Chacun |
| Trailer tonnage | 2 Tonnes / 4000 Lb |
| Volume | 75.8 Cubic Feets |
| 0.3 Wood Cords of (4’x8’x8’) | |
| CHARACTERISTICS | |
| Adjustable 24’’ hydraulic axle | manually |
| Protective Grid | inclusive |
| Number of posts | 8 |
| Tires | 8 ply, 11L15 |
| OPTION | |
| SKI | |
| Gravel bin 7’ | |
| Power unit 5.5HP | |
| Single bolted drawbar with stool |
Log Loader
| Specification | 105-HD |
|---|---|
| Compact Tractors | 20 hp - 40 hp |
| Boom Length | 10'6″ |
| Boom Rotation Swing | 270° |
| Loader Column Height | 53" |
| Lifting Capacity at Maximum Reach | 650 lb. |
| Lifting Capacity at Mid Range | 1,300 lb. |
| Recommended Flow | 3 - 4 gpm |
| Stabilizers | telescopic |
| Grapple Open | 28" |
| Grapple Close | 3" |
| Grapple Rotation (Continuous) | 360° |
| Rotator Maximum Capacity | 1,000 kg. |
| Total Weight (without trailer and hydraulic power unit) | 850 lb. |
| Loader Options | |
| Hydraulic Winch | 4,000 and 6,000 lb. |
| Power Unit (Honda) | 5.5 hp. |
| Bucket | 14″ or 18″ |
