Product Description
Worksaver | 3-Point Bale Spear | Model 830235 To 834100 | Lift Capacity 1,800–6,000 lbs | Horsepower 50 To 70 HP | For Tractors
DESCRIPTION
The WORKSAVER INC. Bale Spear Tractor Attachments are the ultimate solution for fast, safe, and efficient bale handling. Available in a range of models, from 1,800 lbs to 6,000 lbs capacity, these robust bale spears are engineered to make light work of moving round bales. Whether you're lifting small or large bales, WORKSAVER INC. offers the right solution for your tractor, designed with strength, versatility, and ease of use in mind.
Each model features high-quality tapered forged steel spears for excellent bale penetration, reducing damage and enhancing efficiency. Bolt-in design and welded balance spears ensure maximum stability, making these attachments suitable for a variety of bale handling tasks, from farm to ranch. Designed for Cat. I/II tractors and Quick Hitch systems, they integrate easily with your existing equipment, minimizing downtime and boosting productivity.
Whether you’re managing hay, straw, or silage, the WORKSAVER INC. Bale Spear Tractor Attachments are built to perform reliably across a wide range of applications, from small farms to large agricultural operations.
Key Features
- Max Load Capacity: Options range from 1,800 lbs (Model 830235) to 6,000 lbs (Model 834100), making them suitable for light to heavy-duty applications.
- Durable Spear Design: Features 44” tapered forged steel spears for easy bale penetration with minimal damage.
- Welded Balance Spears: Provides added stability, making bale handling smoother and more secure.
- Quick Hitch Compatibility: Easy to connect and disconnect for Cat. I/II tractors—quick setup, minimal downtime.
- Versatile: Suitable for handling both wrapped and unwrapped round bales, ideal for hay, straw, and silage.
- Bolt-in and Welded Construction: Ensures durability, strength, and reliability for long-term use.
- Various Models Available: From single spear models (1,800 lbs) to dual and four-spear models (up to 6,000 lbs), providing a solution for different bale handling needs.
- Made in the USA: Proudly crafted with high-quality materials to meet the demands of modern agriculture.
- Efficient Shipping: Several models are UPS-able, making them easy to receive, transport, and store.
Detailed Specifications
| Feature | Model 830235 | Model 830775 | Model 832310 |
|---|---|---|---|
| Attachment Type | Bale Spear 3PT | Bale Spear 3PT | Bale Spear 3PT |
| Max Load Capacity | 1,800 lbs | 3,000 lbs | 2,200 lbs |
| Spear Length | 44” | 44” | 42” |
| Balance Spears | Welded | Welded | Bolt-in |
| Tractor Compatibility | Cat. I/II | Cat. I/II | Cat. I/II |
| Quick Hitch Compatible | Yes | Yes | Yes |
| Ideal Bale Type | Round Bales (Wrapped/Unwrapped) | Round Bales (Wrapped/Unwrapped) | Round Bales (Wrapped/Unwrapped) |
| Shipping Compatibility | UPS-able | UPS-able | UPS-able |
| Weight | 100 lbs (approx.) | 125 lbs (approx.) | 140 lbs (approx.) |
| Main Material | Forged Steel | Double Forged Steel | Forged Steel |
| Feature | Model 832610 | Model 832615 | Model 834100 |
|---|---|---|---|
| Attachment Type | Four Spear Bale Handler | Triple Bale Spear 3PT | Dual Bale Handler 3PT |
| Max Load Capacity | 4,000 lbs | 3,000 lbs | 6,000 lbs |
| Spear Length | 42” | 26” | N/A |
| Balance Spears | Bolt-in | Bolt-in | N/A |
| Tractor Compatibility | Cat. I/II | Cat. I/II | Cat. I/II |
| Quick Hitch Compatible | Yes | Yes | Yes |
| Ideal Bale Type | Round Bales (Two Bales) | Mid-Sized Square Bales | Round Bales (Two Bales) |
| Shipping Compatibility | N/A | N/A | N/A |
| Weight | 200 lbs (approx.) | 150 lbs (approx.) | 250 lbs (approx.) |
| Main Material | Forged Steel | Forged Steel | Forged Steel |
