Worksaver Hydraulic Post Hole Diggers | Models 924HC | Auger Length 42" | Horsepower 30-60 HP | For Tractors
DESCRIPTION
The Worksaver 924HC-Euro Hydraulic Post Hole Digger is a high-performance, hydraulically driven auger system designed for tractor loaders equipped with the Euro/Global quick attach mounting system. Built for demanding digging tasks, it features a rugged 3.18:1 gearbox with a 2" output shaft, tapered roller bearings, and double-lip spring-loaded seals for long-lasting durability.
Operating at 10–20 GPM and 1500–3000 PSI, the 924HC-Euro delivers powerful torque for efficient hole boring in a wide range of soil conditions. Compatible with augers from 6" to 24" in diameter, including STD, HDSF, and HDDF types, it’s ideal for fencing, landscaping, and utility installations. The bolt-in fish tail auger point ensures stable penetration, while an optional 12" auger extension increases digging depth. With a compact 220 lb frame and a recommended tractor horsepower range of 30–60 HP, this unit combines versatility, strength, and ease of use for professional-grade results.
Key Features
- Euro/Global Quick Attach Mount Compatible with tractor loaders using Euro/Global bucket systems
- Heavy-Duty Gearbox (3.18:1 Ratio) Delivers high torque with 2" output shaft and tapered roller bearings
- Hydraulic Drive System Operates at 10–20 GPM and 1500–3000 PSI
- Auger Compatibility Accepts 6"–24" augers in STD, HDSF, and HDDF formats
- Bolt-In Fish Tail Auger Point Enhances soil penetration and stability
- Optional 12" Auger Extension Part #170705 for deeper digging
- 5-Year Gearbox Warranty Long-term durability and peace of mind
- Horsepower Range Compatible with tractors/loaders rated 30–60 HP
Detailed Specifications
| Attribute | 924HC-Euro |
|---|---|
| Mount Type | Euro/Global |
| Gearbox Ratio | 3.18:1 |
| Output Shaft | 2" |
| Bearings | Tapered Roller |
| Seals | Double Lip, Spring Loaded |
| Drive Type | Hydraulic |
| Hydraulic Flow (GPM) | 10–20 |
| Hydraulic Pressure (psi) | 1500–3000 |
| Auger Sizes | 6"–24" |
| Auger Length | 42" |
| Auger Types | STD, HDSF, HDDF |
| Auger Point | Fish Tail (Bolt-In) |
| 12" Auger Extension | Optional (170705) |
| Weight | 220 lbs |
| Product Number | 702135 |
| Horsepower | 30-60 HP |
