Product Description
York 3-Point Hitch Rotary Broom | YB24 Series | Width 48", 60" & 72" | Hydraulic Drive | Horsepower 20-30 HP | For Tractors
DESCRIPTION
Meet the York YB24 Series 3 Point Hitch Rotary Broom your ultimate solution for efficient and reliable surface cleanup. Designed to mount easily on compact and utility tractors, this hydraulic drive broom tackles snow, leaves, debris, and dethatching with ease, making your outdoor maintenance tasks faster and less strenuous.
With adjustable manual angles of 15 and 30 degrees to either side, you gain precise control over your sweeping path to clean hard-to-reach corners and curbs. The reversible gearbox extends the life of your broom by letting you switch brush rotation effortlessly, while adjustable down pressure ensures optimal contact for all surface types.
Choose from durable poly, wire, or 50/50 brush types tailored to your specific needs, all featuring a robust 24-inch brush diameter that delivers thorough cleaning in every pass. Whether you're maintaining a driveway, parking lot, or farmyard, the YB24 Series combines versatility with durability to get the job done right.
Key Features
- Versatile Width Options: Available in 4 ft, 5 ft, and 6 ft widths to suit various tractor sizes and sweeping needs
- Hydraulic Drive with 540 rpm PTO: Efficient power delivery for consistent broom rotation and performance
- Manual Angle Adjustment: Sweep at 15° or 30° right or left for precision cleaning around obstacles and edges
- Reversible Gearbox: Extend broom life and adapt to different cleaning directions
- Adjustable Broom Down Pressure: Optimize sweeping force for different surfaces and debris types
- Brush Type Flexibility: Select poly, wire, or 50/50 brushes for snow removal, leaf clearing, or heavy-duty cleaning
- Compact & Utility Tractor Compatible: Perfect for small farms, landscaping, and municipal maintenance
- Lightweight & Easy to Maneuver: Weighing between 465-561 lbs for easy transport and operation
Detailed Specifications
| Feature | YB244 (4 ft) | YB245 (5 ft) |
|---|---|---|
| Model Number | 009864H | 009865H |
| Sweeping Width | 4 ft (48") | 5 ft (60") |
| Minimum Sweeping Width | 45" | 55" |
| Brush Diameter | 24" | 24" |
| Weight (without crate) | 465 lbs | 513 lbs |
| Weight (with crate) | 665 lbs | 713 lbs |
| PTO Speed | 540 rpm | 540 rpm |
| Manual Angle Adjustment | 15° & 30° left/right | 15° & 30° left/right |
| Gearbox | Reversible | Reversible |
| Brush Types Available | Poly, Wire, 50/50 | Poly, Wire, 50/50 |
| Feature | YB246 (6 ft) |
|---|---|
| Model Number | 009866H |
| Sweeping Width | 6 ft (72") |
| Minimum Sweeping Width | 65" |
| Brush Diameter | 24" |
| Weight (without crate) | 561 lbs |
| Weight (with crate) | 761 lbs |
| PTO Speed | 540 rpm |
| Manual Angle Adjustment | 15° & 30° left/right |
| Gearbox | Reversible |
| Brush Types Available | Poly, Wire, 50/50 |
