Zipwake Control Panel E with Standard 15M Cable | Model CP-E | 2.8" Dislplay

Zipwake Control Panel E with Standard 15M Cable | Model CP-E | 2.8" Dislplay

$1,890.00
$1,890.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Compact and Lightweight: Designed for easy integration, weighing only 1 lb.
  • Intuitive Controls: Simple and user-friendly interface for seamless operation.
  • Standard 15M Cable: Ensures reliable connectivity and flexible installation.
  • Robust Design: Engineered for durability in marine environments.
  • Compatibility: Designed to work with Zipwake systems for optimized performance.
View full details

Product Description

Zipwake Control Panel E with Standard 15M Cable | Model CP-E | 2.8" Dislplay

DESCRIPTION

Control Panel E with Standard 15M Cable

The Zipwake Control Panel E with Standard 15M Cable is the perfect companion for your Zipwake dynamic trim control system. This compact and lightweight control panel offers intuitive operation, allowing you to fine-tune performance effortlessly.

With a robust design suitable for marine environments, the Control Panel E ensures long-lasting reliability. The included 15-meter cable provides flexibility during installation, making it suitable for various setups. Whether you're upgrading or maintaining your Zipwake system, this control panel delivers optimal performance and ease of use.

Key Features

  • Plug-and-Play Design: Quick and straightforward installation.
  • 15M Standard Cable: Included for enhanced connectivity.
  • Lightweight Construction: Only 1 lb, ensuring minimal weight addition.
  • Marine-Grade Durability: Built to withstand harsh nautical conditions.

Short Facts

  • Fully Automatic
  • Internal GPS & 3D GYRO
  • Waterproof by Design
  • Sunlight Readable
  • Fully automatic - Dynamic pitch and roll control - Steering and turn enhancement
  • Built-in GPS and motion sensors
  • Unique and intuitive 3D controls
  • Sunlight readable color display
  • Instant state user feedback
  • Auto power on/off via ignition key sense
  • Full range of electrical interfaces
  • Waterproof
  • Auto dimming / night mode
  • Upgradable via USB stick
  • Supports up to 3 additional Control Panels in the system
  • Surface, flush or gimbal bracket mount
  • Manages installation configurations from 1 to 6 Series E dual-servo interceptors or any mix with single-servo interceptors
  • Allows configuration of interceptor pair function
  • Auto Cleaning - Selectable periodic cleaning cycle - Prevents fouling inside the interceptor
  • Monitored and/or controlled from external devices, e.g. multifunction displays or plotters via its NMEA 2000 interface

INTERFACES

  • I-BUS IN (CAN bus)
  • I-BUS OUT (CAN bus)
  • NMEA 2000
  • Key sense
  • USB Device Port (Type A)
  • USB Host Port (Type B)
  • External GPS (NMEA 0183 / RS232 auto baud-rate sensing)



Detailed Specifications

Specification CP-E
Display 2.8" IPS Color TFT LCD, 320 x 240 Pixels, Double-Sided, Anti-Reflection Coated Window
Internal Sensors 5 Hz GPS, 3D Gyro, 3D Accelerometer, Ambient Light
Supply Voltage 12 - 32 V DC
Power Consumption 10 W max
Operating Temperature -20° to +85°C (-4° to +185°F)
Storage Temperature -40° to +90°C (-40° to +194°F)
Waterproof Rating IP67 / IP64 (Front / Back)
Compass Safe Distance 0.5 m (1.7 ft)
Compliance CE, FCC
Weight 0.22 kg (0.49 lbs)
Mounting Surface, Flush, or Gimbal Bracket Mount

In Package

  • Included in Kit Boxes
  • Available as an Accessory
  • Available as a Spare Part

Manuals & Documents

Control panel – Installation guide

Control panel – Operator’s startup checklist

Control panel – Operator´s Quick Guide

Product Specifications Document

Latest Software Version
