Zipwake Interceptor 300 S Intermediate | IT 300 S | 11.81" (300mm)
DESCRIPTION
Series S constitutes a product family of four straight, four V-shaped, four chine and one intermediate interceptors. This first-ever modular design made for mass production makes the interceptors durable, affordable and perfectly adapted to any planing or semi-planing boat between 6 m and 15 m (20-50ft).
All components have been meticulously engineered to withstand impact and avoid water ingress, minimizing the risk of costly maintenance and downtime. Interceptor or blade actuation takes place by way of a calibration-free submersible electric servo within the interceptor unit. Its natural water cooling provides excellent working conditions for the brushless DC servo motor, which runs on 12-32 volts. The blade stroke takes 1.5 seconds, outperforming conventional trim tabs by at least a factor of 5.
Installation is made easy with an integral mounting plate and the option of a concealed or above-waterline, self-sealing, thru-hull cable fitting. The preferred mounting option is achieved by simply routing the servo cable differently. Each interceptor comes with the thru-hull cable fitting, cable covers and a practical drill template.
Short Facts:
- Outboard Mount
- Modular Design
- Fast Actuation
-
Calibration Free
Chractristics
- True outboard mount
- Modular design
- Fast actuation
- Submersible servo units
- Brushless 12-24V DC servo
- Calibration free
- High-precision positioning
- Durable and accessible
- Integrated mounting plate
- Thru hull fitting options - Above waterline - Concealed behind interceptor
- No corrosive materials
- Straight, V-shaped, Chine and Intermediate models
Key Features
- Intermediate Blade Design: Tailored for narrow spaces to maintain optimal performance in tight configurations.
- Quick Actuation: High-speed blade stroke of 1.2" with a rate of 0.8 in/s for real-time adjustments.
- Energy Efficient: Automatically reduces wave resistance, enhancing fuel economy and ride comfort.
- Integrated Technology: Features a robust servo actuator, calibration-free operation, and easy accessibility.
- Rugged Build: Waterproof to IP68 standards, resistant to harsh marine environments.
Short Facts:
- Outboard Mount
- Modular Design
- Fast Actuation
-
Calibration Free
Chractristics
- True outboard mount
- Modular design
- Fast actuation
- Submersible servo units
- Brushless 12-24V DC servo
- Calibration free
- High-precision positioning
- Durable and accessible
- Integrated mounting plate
- Thru hull fitting options - Above waterline - Concealed behind interceptor
- No corrosive materials
- Straight, V-shaped, Chine and Intermediate models
Detailed Specifications
| Specification | Details |
|---|---|
| Model | IT 300 S |
| Length | 300 mm (12 inches) |
| Weight | 2.1 kg (4.6 lbs) |
| Max Boat Speed | 60 knots |
| Blade Stroke | 30 mm (1.2 inches) |
| Blade Rate | 20 mm/s (0.8 in/s) |
| Thru-Hull Cable Fitting | Concealed or above waterline |
| Servo Actuator | SU-S |
| Cable Length | 3 m (10 ft), extendable up to 6 m (20 ft) |
| Cable Material | PUR |
| Connector | M12 5-pin circular |
| Connector Diameter | 14.5 mm (0.57 in) |
| Supply Voltage | 12 - 32 V DC |
| Power Consumption | 25 W max |
| Operating Temperature | 0° to +40°C (+32° to +104°F) |
| Storage Temperature | -40° to +90°C (-40° to +194°F) |
| Waterproof Rating | IP68, 5 m (16 ft) |
| Compliance | CE, FCC |
Manuals & Documents
Product Manual
