Arrow Tree Shear Hydraulic Rotate | Model XLR12UN | Size 12" | 5–10 GPM | For Skid Steers
Arrow Tree Shear Hydraulic Rotate | Model XLR12UN | Size 12" | 5–10 GPM | For Skid Steers
Couldn't load pickup availability
Couldn't load pickup availability
Products Description
Arrow Tree Shear Hydraulic Rotate | Model TBL1010UN | Size 10" | 5–10 GPM | For Skid Steers
DESCRIPTION
The Arrow XLR12UN Tree Shear is designed for 12" trees and features a long reach extension adding 7' of reach. With 110° hydraulic rotation, it cuts upward and repositions felled trees efficiently. Built from 1" high‑tensile steel plate, it ensures strength and reliability. Hydraulic flow requirements are 5–10 GPM, with a blade cylinder rated for 3,000 PSI.
The Arrow Tree Shears, originally developed by Sidney Attachments and now available through Arrow Material Handling Products, are built to clear large acreages of invasive trees and shrubs with efficiency. Constructed from 1" high‑tensile steel plate, these shears cut flush with the ground in a single pass. With 110‑degree hydraulic rotation, operators can cut upward and reposition felled trees with ease. Serrated teeth provide grapple‑like functionality to lift and remove debris, while the single blade design directs tree fall in the blade’s travel path. Rated for 3,000 PSI operating pressure and requiring 5–10 GPM hydraulic flow, these shears deliver reliable performance for skid steers, loaders, tractors, and excavators.
Key Features
- Cuts trees up to 12" flush with ground
- Long reach adds 7' of extended cutting capability
- 110° hydraulic rotation for versatile operation
- Serrated teeth for grapple‑like debris removal
- Single blade design for controlled tree fall
- 1" high‑tensile steel plate construction
- Blade cylinder rated for 3,000 PSI
- Hydraulic flow requirement: 5–10 GPM
Detailed Specifications
| Specification | Details |
|---|---|
| Part # | XLR12UN |
| Manufacturer | Arrow |
| Category | Skid Steer Attachments |
| Sub‑Category | Tree Shear Hyd Rotate |
| Industry | Construction |
| Machine Size | SSL |
| Attachment Size | 12" Trees |
| Hydraulic Flow | 5–10 GPM |
| Operating Pressure | 3,000 PSI |
| Notes | Long reach adds 7' |
