Horst Wagons 4-Wheel Wagon Gear | Model 365RF (20 Ton) | Standard Reach Length 10' Ft | Wheelbase Adjustable 10' 7" - 12' 1"| For Agricultural Transport & Forage/Grain Box Applications
Horst Wagons 4-Wheel Wagon Gear | Model 365RF (20 Ton) | Standard Reach Length 10' Ft | Wheelbase Adjustable 10' 7" - 12' 1"| For Agricultural Transport & Forage/Grain Box Applications
Regular price
$10,713.00
Regular price
Sale price
$10,713.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Horst Wagons 4-Wheel Wagon Gear | Model 365RF (20 Ton) | Standard Reach Length 10' Ft | Wheelbase Adjustable 10' 7" - 12' 1"| For Agricultural Transport & Forage/Grain Box Applications
DESCRIPTION
The Horst Wagons 4-Wheel Wagon Gear Model 365RF is designed to meet the rigorous demands of agricultural transport, forage, and grain box applications with a robust 20-ton capacity. Its standard 10-foot reach length, combined with an adjustable wheelbase ranging from 10' 7" to 12' 1", offers exceptional versatility to accommodate various wagon sizes and hauling configurations. Built with heavy-duty materials, this wagon gear integrates advanced Road Flex Suspension technology, which significantly reduces shocks and vibrations for a smoother, more controlled ride on uneven terrain. This enhances operational safety and minimizes wear on equipment. Engineered for longevity and consistent performance, the 365RF ensures dependable hauling, improved handling, and ease of maintenance, making it an indispensable asset for modern agricultural transportation professionals seeking reliability and efficiency in every haul.
Key Features
- Road Flex Suspension: Ensures a smooth, stable ride with reduced vibrations, even on rough terrains.
- Model: 365RF — 20‑Ton Heavy‑Duty Wagon Gear with Road Flex Suspension.
- 20-Ton Capacity: Handles up to 40,000 lbs (18,144 kg) at lower speeds and 36,000 lbs (16,329 kg) at higher speeds.
- Quick Hitch Tongue: Simplifies attachment and detachment for effortless operations.
- Adjustable Wheelbase: Ranges from 10' 7" to 12' 1", offering flexibility for various applications.
- Disc Brake Flanges: Enhanced stopping power for improved safety and control.
- Safety Chain: Includes a 1/2" Grade 70 safety chain for added security.
- Automotive-Style Steering: Greasable tie rod ends and ball joints for long-lasting performance.
- Customizable Rim & Tire Options: Provides compatibility with a range of configurations tailored to your needs.
Detailed Specifications
| Attribute | Specification |
|---|---|
| Brand | Horst Wagons |
| Model | 365RF |
| Type | Heavy‑Duty Tandem Wagon Gear |
| Capacity (30 kph / 20 mph) | 40,000 lb. |
| Capacity (50 kph / 30 mph) | 36,000 lb. |
| Suspension | Road Flex |
| Hubs | 8‑stud |
| Spindles | 3″ dia., 1144 stress‑proof steel |
| Steering | Automotive type |
| Front Axle | 10″ × 4″ × .250 wall |
| Rear Axle | 8″ × 4″ × .188 wall |
| Reach Poles | 3″ O.D. × .188 wall, round tube |
| Reach Tubes | 6″ × 4″ × .188 |
| Standard Reach Length | 10′ |
| Optional Reach Lengths | 8′, 10′, 12′, 14′, 16′, 18′, 20′ |
| Wheelbase | Adjustable 10′ 7″ – 12′ 1″ |
| Tongue Bolt Diameter | 1‑1/8″ |
| Tongue Latch | Retractable automatic relock |
| Tie Rod Ends | Greasable automotive‑style ball joints |
| Bolster Stakes | 42.5″ fixed |
| Tongue Bracket Mounting | 1‑1/2″ bolt bearing mounted |
| Approximate Weight | 3,505 lb. (less rims & tires) |
| Height to Top of Bunk | 39″ (with 445/65 × 22.5 tires) |
| Track Width (Standard) | 86″–93″ (varies by tire) |
| Optional Track Widths | Narrow 60″; wide track up to 90″+ |
| Bearings (Bore Size Inner/Outer) | Taper roller (1.80″ / 1.38″) |
| Brake Options | 2‑wheel or 4‑wheel HD hydraulic disc brakes (22.5 rim) |
| Optional Features | Spring balancers, riser kits |
| Primary Use | Agricultural hauling — forage & grain boxes |
Rim & Tire Options
| Tire Size | Type | Rim Size | Track Width | Capacity (lbs/tire) |
|---|---|---|---|---|
| 16.5 x 16.1 | 10 Ply | 16.1 x W14C x 8 | 93" | 5,200 |
| 19L x 16.1 | 12 Ply | 16.1 x W16C x 8 | 91" | 6,000 |
| 21.5 x 16.1 | 14 Ply | 16.1 x W16C x 8 | 91" | 7,850 |
| 425 x 22.5 | Used Truck | 22.5 x 13 x 8 | 86" | 12,000 |
| 425 x 22.5 | New Truck | 22.5 x 13 x 8 | 86" | 12,000 |
| 445 x 22.5 | New Truck | 22.5 x 13 x 8 | 86" | 12,000 |
| 400 / 55 x 22.5 | 16 Ply | 22.5 x 13 x 8 | 86" | 7,820 |
| 560 / 45 x 22.5 | 16 Ply | 22.5 x 16 x 8 | 92" | 9,640 |
Manuals & Documents
- OPS MANUAL WAGONS
- PARTS MANUAL 365
- HORST WAGONS RUNNING GEAR BROCHURE
- REACH LENGTH CHART
- ASSEMBLY INSTRUCTIONS
- HORST WAGONS CATALOGUE
