The Taylor TDS150 Streamline-Diesel Generator is a robust 150kW power solution engineered with the reliable Perkins 1106D-E70TAG3 engine. This turbocharged, EPA Tier 3-compliant generator delivers exceptional performance and efficiency, meeting the demands of industrial and commercial applications. With advanced electronic CRIN2 fuel injection technology, an air-to-air charge cooling system, and precise isochronous governor control, the TDS150 offers optimized power output, reduced emissions, and seamless operation even under heavy loads.
Taylor Power System Streamline-Diesel Generator | Model TDS150 | Horsepower 232 HP | Power Output 150kW (188kVA)
Taylor Power System Streamline-Diesel Generator | Model TDS150 | Horsepower 232 HP | Power Output 150kW (188kVA)
Regular price
$1.00
Regular price
Sale price
$1.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
How To Request A Quote
***Online pricing not available, Please request a quote:***
How To Get A Quote:
Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!
Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!
Product Description
Taylor Power System Streamline-Diesel Generator | Model TDS150 | Horsepower 232 HP | Power Output 150kW (188kVA)
DESCRIPTION
Key Features
- High Horsepower Output: Produces 232.36 net horsepower with advanced isochronous governor control and ±0.26% speed regulation.
- Turbocharged Efficiency: Turbocharged with air-to-air charge cooling for enhanced power and improved thermal management.
- Emission Compliance: Meets EPA Tier 3 standards for environmentally sustainable operation.
- Durable Vertical Inline Design: Features a robust vertical inline, 4-cycle configuration for reliability and longevity.
- Advanced Fuel Injection: Equipped with electronic CRIN2 technology for precise fuel delivery, maximizing efficiency and reducing operating costs.
- Powerful Cooling System: Radiator airflow of 9,963.1 CFM ensures optimal cooling to maintain peak performance.
- Noise-Reduction Features: Operates at a sound level of 83.0 dBA (with sound-attenuated enclosure) for quieter operation in sensitive environments.
- Streamlined Maintenance: Designed with one air cleaner, one oil filter, and two fuel filters to simplify servicing.
| Controller Data | Feature | Description |
 |
DynaGen Tough Series TG410 Controller |
|
 |
Basler DGC2020ES Controller |
|
 |
DeepSea 6110 MKIII Controller |
|
Detailed Specification
| Category | Details |
|---|---|
| Engine Manufacturer | Perkins |
| Engine Model | 1106D-E70TAG3 |
| Aspiration | Turbocharged |
| EPA Tier | Tier 3 |
| Charge Cooling System | Air-to-Air |
| Arrangement | Vertical Inline, 4-Cycle |
| Displacement | 7.01 L (427.78 in³) |
| Bore x Stroke | 105.00 mm x 135.00 mm (4.13 in x 5.32 in) |
| Compression Ratio | 16.8:1 |
| Net Horsepower | 232.36 |
| Rated RPM | 1800 |
| Speed Regulation | ±0.26% |
| Fuel Injection Type | Electronic CRIN2 |
| Fuel Pump Rate | 104.61 gal/hr (396.00 L/hr) |
| Radiator Air Flow | 9,963.1 CFM (282.1 m³/min) |
| Combustion Air Flow | 540.32 CFM (15.30 m³/min) |
| Fuel Consumption | 12.13 gal/hr (45.90 L/hr) at 100% load |
| Cooling Capacity | 5.55 gal (21.00 L) |
| Oil Capacity | 18.49 qt (17.50 L) |
| Exhaust Gas Temperature | 842.0°F (450.0°C) |
| Exhaust Gas Flow | 1105.4 CFM (31.3 m³/min) |
| Exhaust Outlet Size | 4.56 in. (115.90 mm) |
| Max Back Pressure | 60.20 in. H₂O (15.00 kPa) |
| Battery Voltage | 12 V |
| Cold Cranking Amps | 925 |
| Filters | 1 Air Cleaner, 1 Oil Filter, 2 Fuel Filters |
| Sound Level (Open Unit) | 98.8 dBA (3.2 ft without exhaust) |
| Sound Level (Attenuated) | 83.0 dBA (23 ft full load) |
